Mean Well GSM12U07-P1J Power Supply 12W 7.5V
FCC part 15/CISPR22 Class B
Key Features
- ✓✓Universal AC input / Full range
- ✓✓Energy efficiency level VI
- ✓✓Medical safety approved (2 x MOPP)
- ✓✓Extremely low leakage current
- ✓✓No load power consumption < 0.075W(<0.1W for 18V/48V)
- ✓✓High efficiency up to 87%
- ✓✓Class II power (without earth pin)
- ✓✓Protections: Short circuit / Overload / Over voltage
- ✓✓Fully enclosed plastic case
- ✓✓100% full load burn-in test
- ✓✓3 years warranty
-
BrandMean Well
-
SeriesGSM Series
-
Power Rating12 Watt
-
Output Voltage7.5 Volt
-
Rated Current1.6 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetEAC,FCC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length2.45 in
-
Width1.79 in
-
Height1.08 in
-
Weight0.24 lb
::specification::
Frequently Asked Questions
Can I use the GSM12U07-P1J for a 7.5V embedded device or controller?
Yes, if the device requires constant-voltage 7.5V DC and stays within 1.6A and 12W. That makes it relevant for lower-power embedded, control, or interface electronics built around a 7.5V input requirement.
Is this 7.5V supply suitable for a small industrial instrument that runs on 7.5V?
It can be a fit for a small industrial instrument when the instrument is rated for constant-voltage 7.5V input. The output limit is 1.6A with 12W maximum power.
Can the GSM12U07-P1J power a compact automation accessory that needs 7.5V DC?
It is intended for 7.5V constant-voltage loads, so it can support compact automation accessories designed for that input. The accessory must remain within 1.6A current draw and 12W total load.
How should I check compatibility for a 7.5V device with this adapter?
Match the device to a constant-voltage 7.5V supply and confirm that its demand does not exceed 1.6A or 12W. If either the current or total power requirement is higher, this model is not the right size.
Is the GSM12U07-P1J meant for outdoor environments?
The listed temperature range is -20°C to +70°C, which supports a broad range of operating conditions for indoor equipment. Since no IP rating is provided in the product data, the specs here do not verify outdoor suitability.
