Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well GSM12U24-P1J Power Supply 12W 24V
FCC part 15/CISPR22 Class B
Key Features
- ✓✓Universal AC input / Full range
- ✓✓Energy efficiency level VI
- ✓✓Medical safety approved (2 x MOPP)
- ✓✓Extremely low leakage current
- ✓✓No load power consumption < 0.075W(<0.1W for 18V/48V)
- ✓✓High efficiency up to 87%
- ✓✓Class II power (without earth pin)
- ✓✓Protections: Short circuit / Overload / Over voltage
- ✓✓Fully enclosed plastic case
- ✓✓100% full load burn-in test
- ✓✓3 years warranty
-
BrandMean Well
-
SeriesGSM Series
-
Power Rating12 Watt
-
Output Voltage24 Volt
-
Rated Current0.5 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetEAC,FCC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty3 Year
-
Length2.45 in
-
Width1.79 in
-
Height1.08 in
-
Weight0.24 lb
::specification::
Frequently Asked Questions
Can I use the GSM12U24-P1J for a small 24V PLC accessory or control module?
Yes, this model provides constant 24V output and is rated for 0.5A, so it fits low-power 24V control accessories that stay within 12W. It is intended for electronics that require a fixed 24V DC source rather than variable output.
Is this a suitable 24V supply for embedded or industrial IoT equipment?
It can be a fit for embedded or industrial IoT hardware that needs 24V DC and draws no more than 0.5A. With 80-264VAC input support, it is also practical for deployments where incoming AC may vary.
Would this 24V adapter work for a compact sensor hub or signal interface?
Yes, for a 24V sensor hub or signal interface with a light power requirement, this unit can be appropriate. The key limit is the 12W, 0.5A output rating, so the connected load must remain under that capacity.
Can the GSM12U24-P1J power a small bench-top 24V test setup?
It can, provided the test setup is designed for constant 24V input and the load stays within 0.5A. Its compact 62.2 × 45.5 × 27.4 mm size also makes it easier to place in tight test or service areas.
Is this 24V power supply intended for indoor or outdoor environments?
No IP rating is shown in the provided specs, so this supply should be considered for indoor or otherwise protected use unless the final product enclosure adds environmental sealing. Its operating temperature range of -20°C to +70°C supports use across a wide temperature span in sheltered conditions.
