Mean Well APC-25-700 Power Supply 25W 700mA
The APC-25 is a 25W Mean Well. power converter. and an input range of 25~70V.
Key Features
- ✓ Input voltage range: 25~70V
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~70℃
- ✓ Protections: Over voltage
- ✓ Safety approvals: UL8750 (except for APC-25-350), CSA-C22.2 No. 250.0-13 (only for APC-25-700&1050), IP42
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesAPC Series
-
Power Rating25.2 Watt
-
Output Voltage36 Volt
-
Rated Current0.7 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSMI,CE,cUL,EAC
-
Operation ModeConstant Current
-
Operating Temperature-30°C~70°C
-
Warranty2 Year
-
Length3.31 in
-
Width2.24 in
-
Height1.16 in
-
Weight0.29 lb
::specification::
Frequently Asked Questions
What is the APC-25-700 typically used for?
The Mean Well APC-25-700 is typically used for constant-current LED lighting and moving sign applications that need a 700mA drive current with more power headroom than smaller APC models. With 25.2W rated power, it is a fit for 700mA LED loads that need more output capacity than the 12W and 16W versions.
Is the APC-25-700 a good fit for 700mA LED loads that need more output than the APC-16-700?
Yes. Both models are 700mA constant-current drivers, but the APC-25-700 provides 25.2W compared with 16.8W on the APC-16-700. That makes it a better fit when the LED load still needs 700mA but requires more output capability.
Can the APC-25-700 be used for indoor LED lighting or sign projects?
Yes. The APC-25-700 is positioned for LED lighting and moving sign applications, so indoor lighting and sign assemblies are typical uses when the connected load is designed for 700mA constant-current operation and fits within the driver's electrical rating.
Will the APC-25-700 run on common AC mains supplies?
Yes. The specified input range is 90-264VAC, so the APC-25-700 can operate from common 120V and 240V mains systems within that range. That makes it practical for broad indoor lighting deployment.
Is the APC-25-700 suitable for exposed outdoor installation?
No. The APC-25-700 has an IP30 design, so it should generally be used indoors or in a protective enclosure rather than in direct outdoor exposure. Its listed working temperature is -30°C to +70°C, but ingress protection remains limited.
How does the APC-25-700 compare with APC-16-700 and APC-25-500?
The APC-25-700 provides 25.2W at 700mA, giving it more output capacity than the APC-16-700 at 16.8W and 700mA. Compared with the APC-25-500, the main difference is current level: the APC-25-700 is for 700mA LED loads, while the APC-25-500 is for 500mA loads. The key selection rule is matching the driver current to the LED requirement.
