Mean Well LPF-25-20 Power Supply 25W 20V 1.25A
The LPF-25 is a 25W Mean Well power converter.
Key Features
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.8 SAFETY & EMC
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesLPF Series
-
Power Rating25 Watt
-
Output Voltage20 Volt
-
Rated Current1.25 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,ENEC,PSE,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-35°C~70°C
-
Warranty5 Year
-
Length5.83 in
-
Width1.57 in
-
Height1.26 in
-
Weight0.79 lb
::specification::
Frequently Asked Questions
Can I use the LPF-25-20 for a 20V LED strip or linear light run?
Yes, if the strip or fixture is designed for 20V operation and the total load stays within 25W. This driver provides 20V at 1.25A, so it fits smaller 20V lighting sections rather than larger runs. Check the light’s rated voltage and total power before selecting it.
Is the LPF-25-20 suitable for compact illuminated signage?
It can be a fit for compact 20V sign lighting when the load does not exceed 25W. The IP67 waterproof rating is useful for sign installations exposed to dust or water. Confirm the sign lighting modules are rated for 20V and stay within 1.25A.
Can this model be used for small 20V accent or cove lighting?
Yes, for small 20V accent or cove lighting sections that stay within the 25W output limit. Its 20V output and 1.25A current make it appropriate for lower-power applications with matching electrical requirements. Verify the fixture or strip specification before use.
Is the LPF-25-20 appropriate for outdoor or damp environments?
Yes, the driver is rated IP67 waterproof, so it is built for wet and dusty conditions. It also operates from -35°C to +70°C, which supports many indoor and outdoor locations. The connected lighting product still needs its own environmental rating.
How many meters of 20V LED strip can the LPF-25-20 support?
Estimate the run by dividing the driver’s 25W maximum by the strip’s watts per meter. Length = 25W divided by rated W/m, so a 5W/m strip would be about 5 meters. Check your strip rated power per meter before sizing the final run.
How does the LPF-25-20 compare with other 20V options in the LPF line?
For 20V models, the series includes LPF-16-20 at 16W and 0.8A, LPF-25-20 at 25W and 1.25A, LPF-40-20 at 40W and 2A, LPF-60-20 at 60W and 3A, and LPF-90-20 at 90W and 4.5A. The dimmable counterparts keep the same 20V output levels as LPF-16D-20, LPF-25D-20, LPF-40D-20, LPF-60D-20, and LPF-90D-20.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other LPF-25 Models
1 other model| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well LPF-25-12 Power Supply 25W 12V | 25.2W | 12V | 2.1A | IP67 | $23.06 | View |
