Mean Well NTU-1700-148US True Sine Wave DC-AC Inverter 1700W 110V out 48V in with US Socket, with AC by-pass function
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well NTU-1700-148US True Sine Wave DC-AC Inverter 1700W 110V o...
The NTU-1700 is a 1700W Mean Well power converter (input range: 10~16.5Vdc).
Key Features
- ✓ Input voltage range: 10~16.5Vdc
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature / Reverse polarity
- ✓ Remote ON/OFF control
- ✓ Safety approvals: CB IEC62368-1,Dekra BS EN/EN62368-1,UL458, E13,EAC TP TC 004,AS/NZS 62368.1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesNTS Series
-
Power Rating1700 Watt
-
Output Voltage110 Volt
-
Input Voltage40V~66V
-
No of Output1
-
Standards MetCB,CE,cUL,E13,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-25°C~70°C
-
Warranty3 Year
-
Length15.75 in
-
Width7.24 in
-
Height2.76 in
-
Weight10.21 lb
::specification::
Frequently Asked Questions
What is the Mean Well NTU-1700-148US designed for?
The NTU-1700-148US is a true sine wave DC-AC inverter that converts 48V DC input to 110V AC output for powering AC equipment. It is built for higher-power applications that need up to 1700W continuous output and also includes an AC by-pass function for UPS-style operation.
What type of AC output does this inverter provide?
This model provides a true sine wave AC output with total harmonic distortion below 3%. That makes it a better fit for sensitive electronics and loads that benefit from cleaner AC power compared with modified sine wave designs.
What are the input and output ratings of the NTU-1700-148US?
This inverter is rated for 48V DC input and 110V AC output, with 1700W continuous power. It also supports high surge power up to 3400W, which helps with loads that draw extra power briefly at startup.
Does the NTU-1700-148US support battery backup style operation?
Yes. This model includes a built-in UPS function with AC by-pass capability, which is one of its key differentiators. It also includes battery over-discharge protection to help protect the connected battery system from low-voltage conditions.
Is this inverter compatible with different battery chemistries?
Yes, the NTU-1700-148US is suitable for both lead-acid and lithium-ion batteries. The product data specifically lists support for those battery types, making it more flexible for industrial, mobile, and backup power applications.
Can this inverter be used in demanding temperature conditions?
It is designed for a wide operating temperature range of -25°C to +70°C, subject to the output derating curve. It also uses a temperature-controlled cooling fan and conformal coating, which supports use in tougher operating environments.
Can the output voltage and frequency be adjusted on this model?
Yes. The AC output voltage and frequency are selectable by DIP switch, and the listed voltage options include 100/110/115/120VAC and 200/220/230/240VAC. This gives the NTU series broader deployment flexibility, although this specific version is sold as a 110V output model with a US socket.
What protections and certifications does the NTU-1700-148US include?
This inverter includes short circuit, overload, over-voltage, and battery over-discharge protection. It is also listed with safety approvals including IEC62368-1, EN62368-1, and UL458, with EMC compliance including EN55032 Class A.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other NTU-1700 Models
5 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well NTU-1700-248AU True Sine Wave DC-AC Inverter 1700W 220V out 48V in with AU Socket, with AC by-pass function | 1700W | 240V | — | Indoor | $441.62 | View |
| Mean Well NTU-1700-224AU True Sine Wave DC-AC Inverter 1700W 220V out 24V in with AU Socket, with AC by-pass function | 1700W | 220V | — | Indoor | $441.62 | View |
| Mean Well NTU-1700-212AU True Sine Wave DC-AC Inverter 1700W 220V out 12V in with AU Socket, with AC by-pass function | 1700W | 200V | — | Indoor | $441.62 | View |
| Mean Well NTU-1700-124US True Sine Wave DC-AC Inverter 1700W 110V out 24V in with US Socket, with AC by-pass function | 1700W | 110V | — | Indoor | $436.88 | View |
| Mean Well NTU-1700-112US True Sine Wave DC-AC Inverter 1700W 110V out 12V in with US Socket, with AC by-pass function | 1700W | 110V | — | Indoor | $436.88 | View |
