Boxco Push Button Box, 3.15 x 2.95 x 2.24 Inches(80 x 75 x 57mm) 1 ...
Boxco push button enclosures are made from ABS and polycarbonate material. It has 1-3 push button entries and molded knock outs in base for easy installation. This product does not require additional machining when installing 22, 25 or 30 push button and switches.
Features
- Screw type
- This series has a pre-cut hole on the cover
-
BrandBoxco
-
SeriesBoxco Aluminium Series
-
MaterialAluminium
-
Base ColorSilver
-
Cover ColorSilver
-
Standards MetCE,DIN,ROHS,TUV,UL
-
Operating Temperature-40°C~85°C
-
Warranty1 Year
-
Length3.15 in
-
Width2.95 in
-
Height2.24 in
-
Weight0.71 lb
::specification::
Frequently Asked Questions
What is this Boxco push button box designed for?
This model is a compact push button enclosure for control and interface applications that need a dedicated single button opening. It is suited to industrial and commercial environments where a protective enclosure with a pre-cut hole and durable housing is needed.
How many push button openings does this model have?
This specific model has 1 pre-cut hole on the cover. That makes it a better fit for single-button or single-device layouts than multi-opening push button boxes.
What size is this enclosure?
The enclosure measures 3.15 x 2.95 x 2.24 inches, which is 80 x 75 x 57 mm. Its compact size helps when panel space or mounting area is limited.
Is this push button box suitable for harsh environments?
Yes. This model is rated IP67 for dust-tight and water-resistant protection and IK10 for high impact resistance. It is built for demanding environments where enclosure durability matters.
What temperature range can this enclosure handle?
This model is rated for temperatures from -40 °C to 85 °C. That range supports use in both very cold and high-heat operating environments within the stated limits.
What material and construction does this model use?
This product is identified as an aluminium die casting push button box. That construction supports a robust enclosure style for applications that need a durable metal housing.
How does this model compare with larger push button enclosures?
This model is a smaller single-hole enclosure, so it is best when you only need one control point in a compact footprint. Larger enclosures are more appropriate when the application requires additional button openings or more internal space.
