Boxco Push Button Box, 3.15 x 6.89 x 2.24 Inches(80 x 175 x 57mm) 3...
Boxco push button enclosures are made from ABS and polycarbonate material. It has 1-3 push button entries and molded knock outs in base for easy installation. This product does not require additional machining when installing 22, 25 or 30 push button and switches.
Features
- Screw type
- This series has a pre-cut hole on the cover
-
BrandBoxco
-
SeriesBoxco Aluminium Series
-
MaterialAluminium
-
Base ColorSilver
-
Cover ColorSilver
-
Standards MetCE,DIN,ROHS,TUV,UL
-
Operating Temperature-40°C~85°C
-
Warranty1 Year
-
Length3.15 in
-
Width6.89 in
-
Height2.24 in
-
Weight1.29 lb
::specification::
Frequently Asked Questions
What is this Boxco push button box typically used for?
This model is intended for push button and switch enclosure applications where a compact, durable housing is needed. Its 3-hole cover and industrial enclosure format make it relevant for control and operator interface use in commercial or industrial settings.
How many push button openings does this model have?
This specific model has 3 pre-cut holes on the cover. That makes it a better fit than a blank enclosure when your application already calls for a three-position push button layout.
What protection level does this enclosure provide?
This model is rated IP67 and IK10. That means it is built for strong resistance to dust and water ingress and also offers high impact resistance for demanding environments.
What size is this enclosure?
The enclosure measures 3.15 x 6.89 x 2.24 inches, which is 80 x 175 x 57 mm. That size provides a narrow rectangular form factor that can suit applications needing three cover openings without using a much larger box.
What temperature range can this push button box handle?
This model is listed for use from -40 degrees C to 85 degrees C. That wide operating range makes it suitable for many indoor and outdoor industrial environments where temperature swings are a concern.
Is this model compatible with common push button sizes?
The product description states that Boxco push button enclosures in this line do not require additional machining when installing 22, 25, or 30 push buttons and switches. For this 3-hole model, that is a useful compatibility point if your project uses those standard push button sizes.
What are the warranty period and product weight for this model?
This enclosure has a listed warranty period of 1 year. Its listed weight is 0.5860 kg, which can be useful when comparing enclosure options for handling, panel design, or shipping considerations.
