Boxco S-Series 4.92 x 4.92 x 3.94 Inches(125x125x100mm) Plastic Enc...
For Boxco S-Series, Ultraviolet Stabilizer is added to protect the enclosures for outdoor usage. Few colour changes will be noticed even after a long time of use. Anti-static material is used to protect sensitive electronic instruments from static electricity. It is made of high impact resistant material which is very strong against external impact and also prevents breakage during hole and press processing. Special spec can be added besides standard specification. We can supply optimized products with the spec and material you choose.
Features
- Mounting Plate Attachment Point – Internal mounting plate can be fixed tightly onto the brass inserted injection molding to handle heavy equipment installed inside the enclosure
- Pre-molded Mounting Screw Nuts – You can easily fix DIN RAIL or other equipment on to the pre molded Screw nuts
- Gasket – The gasket in injected by super precise CNC robot machine to product excellent waterproof and dust-proof performance
- Cover Bolt Attachment Point – Screw thread was made in injection molding to ensure maximum strength
-
BrandBoxco
-
SeriesBoxco S Series
-
MaterialPC
-
Base ColorGrey
-
Cover ColorGrey
-
Standards MetCE,TUV,UL
-
Operating Temperature-40°C~110°C
-
Warranty1 Year
-
Length4.92 in
-
Width4.92 in
-
Height3.94 in
-
Weight0.8 lb
::specification::
Frequently Asked Questions
What applications is the Boxco S-Series BC-CGS-121210 plastic enclosure suited for?
This model is suited for protecting sensitive electrical or electronic components in industrial and outdoor environments where dust, water, and impact resistance matter. Its anti-static material and UV-stabilized construction make it a practical choice for control, monitoring, or protection equipment housings.
What are the key size and material specifications of this enclosure?
The BC-CGS-121210 measures 4.92 x 4.92 x 3.94 inches, which corresponds to 125 x 125 x 100 mm. It is made from PC material and comes with a grey cover in a screw-type enclosure design.
Is this enclosure suitable for outdoor or harsh environments?
Yes, this enclosure is designed for demanding environments with an IP67 rating for dust-tight and water-resistant protection and an IK08 impact rating. It also includes an ultraviolet stabilizer to reduce color change over long-term outdoor exposure.
What temperature range can this enclosure handle?
This model is rated for use from -40 °C to 110 °C. That range supports use in both cold and high-heat environments where standard plastic housings may be less suitable.
How does this model support internal equipment mounting?
The enclosure includes mounting plate attachment points with brass inserted injection molding for securely holding heavier internal equipment. It also has pre-molded mounting screw nuts that support adding DIN rail or other internal hardware.
What distinguishes this Boxco S-Series screw-type enclosure from a basic plastic box?
This model combines IP67 sealing, IK08 impact resistance, UV-stabilized PC material, and anti-static properties in one enclosure. It also includes molded features for stronger cover fastening and more secure internal mounting, which makes it more purpose-built than a generic plastic box.
What warranty and product weight should buyers expect for this model?
The listed warranty period for the BC-CGS-121210 is 1 year. The enclosure weight is 0.362 kg, which can be useful when planning handling, shipping, or panel load considerations.
