Mean Well CSP-3000-120 Power Supply with Single Output 3000W 250V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well CSP-3000-120 Power Supply with Single Output 3000W 250V
The CSP-3000 is a 3000W Mean Well. power converter.
Key Features
- ✓ 3KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Remote ON/OFF control
- ✓ Current sharing up to 9000W (parallel units)
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesCSP Series
-
Power Rating3000 Watt
-
Output Voltage250 Volt
-
Rated Current12 Ampere
-
Input Voltage180V~264V
-
No of Output1
-
Standards MetCB,CE,DEKRA,EAC,ENEC,FCC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~60°C
-
Warranty5 Year
-
Length10.94 in
-
Width7 in
-
Height2.5 in
-
Weight8.82 lb
::specification::
Frequently Asked Questions
What is the CSP-3000-250 typically used for?
The Mean Well CSP-3000-250 is typically used in high-power 250V DC applications that need a single-output 3000W enclosed power supply. With 250V output at 12A, it is intended for demanding industrial and specialized high-voltage DC systems rather than low-voltage general-purpose loads.
Is the CSP-3000-250 suitable for large high-voltage DC loads?
Yes. The CSP-3000-250 provides 3000W at 250V and 12A, which makes it suitable for heavy-duty high-voltage DC applications that need substantially more power than lower-wattage enclosed supplies can deliver.
Can the CSP-3000-250 be used in systems that need adjustable output behavior?
Yes. The published features list programmable output voltage and current, so the CSP-3000-250 is relevant for applications that need a more configurable high-power DC source instead of a strictly fixed-output platform.
Does the CSP-3000-250 support larger-capacity multi-unit systems?
Yes. The product features include active current sharing up to 9000W, which makes the CSP-3000-250 suitable for larger system architectures where multiple units may be combined to increase total output capacity.
What AC input range does the CSP-3000-250 support?
The specified AC input range is 180-264VAC, with 254-370VDC also listed. That makes the CSP-3000-250 appropriate for 230V-class AC mains environments and other installations that fall within those published ranges.
Is the CSP-3000-250 intended for exposed outdoor installation?
The current product data does not list a waterproof IP rating, so the CSP-3000-250 should be installed in a protected indoor or cabinet environment rather than directly exposed outdoor conditions. Its working temperature is listed as -25°C to +65°C, but enclosure protection is still required.
How does the CSP-3000-250 compare with CSP-3000-120 and CSP-3000-400?
All three models are in the 3000W CSP family, but they target different output voltage classes. The CSP-3000-120 provides 120V at 25A, the CSP-3000-250 provides 250V at 12A, and the CSP-3000-400 provides 400V at 7.5A. The right choice depends primarily on the DC output voltage your system is designed to use.
What published high-end features does the CSP-3000-250 include?
The published features include active PFC, up to 93% efficiency, programmable output voltage and current, active current sharing up to 9000W, built-in remote ON-OFF control, auxiliary power, power OK signal, conformal coating, and a 5-year warranty. Listed protections include short circuit, overload, over-voltage, over-temperature, and fan failure protection.
