Mean Well DETN02L-15 DC-DC Converter - 2W - 4.5~5.5V in ±15V out 67mA
The DETN02L-15 is a 2W Mean Well DC-DC converter (input: 4.5~5.5VDC, operating temperature: -40~+100°C).
Key Features
- ✓ Input voltage: 4.5~5.5VDC
- ✓ Output voltage (max): 15V
- ✓ Rated output current: 0.067A
- ✓ I/O isolation: 3000V
- ✓ Operating temperature: -40~+100°C
- ✓ Safety certifications: CE, EMC
- ✓ 3 year warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating2 Watt
-
Output Voltage15 Volt
-
Rated Current0.06 Ampere
-
Input Voltage4.5V~5.5V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~100°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN02L-15 for ±15V signal-conditioning circuits in industrial electronics?
Yes, it is intended for constant-voltage ±15V output and is rated at 2W. That makes it relevant for low-power signal-conditioning, interface, or analog support sections that need a higher output voltage than the 5V or 12V variants.
Is the DETN02L-15 appropriate for embedded instrumentation that needs a low-power ±15V rail?
It can be used where the instrumentation design requires ±15V output and stays within the 2W and 0.07A limits. The compact 15.24 × 10.9 × 7.1 mm body also helps when the converter must fit into a small embedded assembly.
Would this model fit low-power automation modules that need higher-voltage auxiliary power?
Within the DETN02L family, this is the highest listed output-voltage option at 15V. For low-power automation or control circuitry that needs constant-voltage ±15V from a 4-5VAC input, it is the appropriate series choice if the load remains within 2W.
Can the DETN02L-15 be used in compact data acquisition or test equipment?
It is suitable for low-power sections of test, measurement, or data-acquisition hardware that need ±15V output. Its small size, 0.0012 kg weight, and wide -40°C to +100°C operating temperature range support use inside compact electronic equipment.
Is the DETN02L-15 suitable for outdoor cabinets or exposed installations?
The temperature specification is -40°C to +100°C, which covers a wide operating range. However, no IP rating is listed, so the provided specs do not confirm resistance to dust, water, or direct outdoor exposure.
How does the DETN02L-15 differ from the 5V and 12V versions in the same series?
All listed DETN02L siblings are 2W converters, but they differ by output voltage and current. The DETN02L-05 is 5V at 0.2A, the DETN02L-12 is 12V at 0.08A, and the DETN02L-15 is 15V at 0.07A. The 15V model is the highest-voltage option among the three.
