Mean Well DETN01L-05 DC-DC Converter - 1W - 4.5~5.5V in ±5V out
The DETN01L is a 1W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.1 Ampere
-
Input Voltage4.5V~5.5V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN01L-05 to power low-power analog circuitry in an embedded controller?
Yes, this model is intended for low-power constant-voltage conversion at 1W with a ±5V output. It is a fit for small analog sections in embedded or industrial electronics where a 4.5~5.5V input and ±5V rails are required.
Is the DETN01L-05 suitable for isolated signal-conditioning stages in industrial equipment?
It can be used for low-power signal-conditioning or interface sections that need ±5V from a 4.5~5.5V input. The 1W rating makes it appropriate for control and measurement circuitry rather than larger loads.
Can this converter be used inside compact automation or IT hardware with limited board space?
Yes, the module is very compact at 15.24 × 10.9 × 7.1 mm and weighs 0.0012 kg. That size is useful in dense embedded, automation, or IT assemblies that need a small 1W DC-DC converter.
Is the DETN01L-05 appropriate for outdoor or harsh-environment use?
The listed operating temperature is -40°C to +90°C, which covers a wide temperature range. No IP rating is provided in the specs, so protection against water or dust exposure is not stated.
How does the DETN01L-05 compare with the other DETN01L models?
Within this series, the DETN01L-05 is rated at 1W with a 5V output and 100A listed output current. The DETN01L-12 is 1W with 12V output at 0.04A, and the DETN01L-15 is 1W with 15V output at 0.03A.
