Mean Well DETN01L-12 DC-DC Converter - 1W - 4.5~5.5V in ±12V out
The DETN01L is a 1W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating1 Watt
-
Output Voltage12 Volt
-
Rated Current0.04 Ampere
-
Input Voltage4.5V~5.5V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN01L-12 for low-power analog sections in industrial control electronics?
Yes, this converter is suited to low-power constant-voltage applications that need a ±12V output from a 4.5~5.5V input. With a 1W rating, it fits small analog sections in industrial or embedded control hardware.
Is the DETN01L-12 a fit for sensor or measurement interface circuits that need ±12V rails?
It can be used where the circuit requires ±12V and the total power stays within 1W. That makes it better aligned with signal-level measurement, sensing, or interface electronics than with higher-power loads.
Can this model work in compact automation boards or communication equipment?
Yes, its 15.24 × 10.9 × 7.1 mm package and 0.0012 kg weight make it practical for compact embedded, automation, and IT assemblies. It is intended for constant-voltage conversion in small spaces.
Is the DETN01L-12 suitable for indoor cabinets that see wide temperature swings?
The specified operating range is -40°C to +90°C, so it is rated for broad temperature conditions. No IP rating is listed, so the specs do not confirm suitability for direct outdoor exposure or washdown areas.
What is the difference between the DETN01L-12 and the other models in the series?
The DETN01L-12 is a 1W model with 12V output and 0.04A output current. The DETN01L-05 is 1W with 5V output and 100A listed output current, while the DETN01L-15 is 1W with 15V output and 0.03A.
