Mean Well DETN01L-15 DC-DC Converter - 1W - 4.5~5.5V in ±15V out
The DETN01L is a 1W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.03 Ampere
-
Input Voltage4.5V~5.5V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN01L-15 for low-power analog or interface circuits in automation equipment?
Yes, it is designed for constant-voltage conversion at 1W with a ±15V output from a 4.5~5.5V input. That makes it suitable for low-power analog and interface sections in embedded or automation hardware.
Is the DETN01L-15 appropriate for instrumentation electronics that require ±15V rails?
It is a fit for low-power instrumentation or control circuitry that specifically needs ±15V. The 1W rating means it should be used for small electronic sections rather than heavier-power devices.
Can this converter be used where board space is tight in industrial or embedded designs?
Yes, the 15.24 × 10.9 × 7.1 mm size supports compact board layouts. At 0.0012 kg, it is also lightweight for dense embedded, IT, or industrial electronics assemblies.
Will the DETN01L-15 handle demanding temperature conditions?
The operating temperature range is -40°C to +90°C, so it is specified for wide temperature conditions. Because no IP rating is listed, the product data does not define resistance to water or dust exposure.
How does the DETN01L-15 differ from the DETN01L-05 and DETN01L-12?
The DETN01L-15 is the 1W version with 15V output and 0.03A output current. In the same series, the DETN01L-05 is 1W with 5V output and 100A listed output current, and the DETN01L-12 is 1W with 12V output at 0.04A.
