Mean Well DETN01M-05 DC-DC Converter - 1W - 10.8~13.2V in ±5V out
The DETN01M is a 1W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.1 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN01M-05 for 5V logic in industrial control electronics?
Yes, it is a constant-voltage DC-DC converter with a 5V output and a 1W power rating. That makes it a fit for low-power 5V control, monitoring, or signal-level electronics where the load stays within 1W.
Is the DETN01M-05 suitable for embedded 5V sensor or controller circuits?
It can be used for embedded circuits that need a regulated 5V rail and only require 1W of output power. This is better aligned with low-power sensors, small controller boards, and auxiliary logic than with larger 5V loads.
Can this converter be used inside automation equipment for isolated 5V housekeeping power?
It is intended for very small auxiliary power duties where 5V constant-voltage output is needed and the total demand fits within 1W. In automation equipment, that points to light housekeeping or interface-level electronics rather than higher-draw devices.
Is the DETN01M-05 appropriate for outdoor or harsh-environment use?
The operating temperature range is -40°C to +90°C, so the temperature rating is broad. However, no IP rating is listed, so it should be treated as a board-level part for protected enclosures rather than direct outdoor exposure.
How does the DETN01M-05 compare with the other DETN01M models?
All three models in the series are 1W converters. The DETN01M-05 has 5V output, while the DETN01M-12 is 12V at 0.04A and the DETN01M-15 is 15V at 0.03A.
