Mean Well DETN01M-12 DC-DC Converter - 1W - 10.8~13.2V in ±12V out
The DETN01M is a 1W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating1 Watt
-
Output Voltage12 Volt
-
Rated Current0.04 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN01M-12 for 12V analog or signal-conditioning circuits?
Yes, it is a constant-voltage converter with a 12V output and a 1W power rating. That suits low-power analog, instrumentation, or signal-conditioning sections that need a small 12V rail.
Is the DETN01M-12 a fit for embedded measurement or control boards that need 12V?
It can fit embedded boards that require 12V auxiliary power as long as the load stays within 1W. The rated output current is 0.04A, so it is aimed at light-duty support circuitry rather than larger 12V devices.
Can this model be used for low-power 12V interface power in industrial automation equipment?
It is suitable when the automation circuit needs a regulated 12V output for a small interface, sensing, or control stage. With 1W output capacity, it is best matched to low-power electronics instead of heavier 12V loads.
Will the DETN01M-12 handle cold or hot enclosure conditions?
Its specified operating temperature range is -40°C to +90°C, which supports wide temperature operation in protected equipment. No IP rating is listed, so environmental suitability should be judged as enclosed indoor electronics use rather than exposed outdoor use.
What is the difference between the DETN01M-12 and the other DETN01M versions?
Each model in the family is rated at 1W, but the outputs differ. The DETN01M-05 is 5V, the DETN01M-12 is 12V at 0.04A, and the DETN01M-15 is 15V at 0.03A.
