Mean Well DETN01N-05 DC-DC Converter - 1W - 21.6~26.4V in ±5V out
The DETN01N is a 1W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating1 Watt
-
Output Voltage5 Volt
-
Rated Current0.1 Ampere
-
Input Voltage21.6V~26.4V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN01N-05 to power 5V logic in a 24V industrial control panel?
It can fit low-power 5V logic applications when the source available to the converter is within the listed 21-26VAC input range. The output is constant-voltage 5V with 1W rated power, so it is best suited to small control, monitoring, or interface circuits rather than larger loads.
Is the DETN01N-05 suitable for embedded monitoring or sensing electronics inside industrial equipment?
Yes, it is sized for low-power embedded electronics that need a regulated 5V rail from a nominal 24V class input range of 21-26VAC. Its compact 15.24 × 10.9 × 7.1 mm package also makes it easier to use where board space is limited.
Can this 1W converter be used for low-power automation interface modules?
It is appropriate for low-power automation interfaces that need constant-voltage 5V output and only require 1W of power. Buyers should match the load to the listed 5V output and 1W rating instead of using it for higher-power automation hardware.
How does the DETN01N-05 compare with the DETN01N-12 and DETN01N-15?
All three models are 1W DC-DC converters with the same 21-26VAC input range, 15.24 × 10.9 × 7.1 mm dimensions, -40°C to +90°C operating range, and 3-year warranty. The difference is the output: DETN01N-05 is 5V at 100A, DETN01N-12 is 12V at 0.04A, and DETN01N-15 is 15V at 0.03A.
Is the DETN01N-05 suitable for outdoor or harsh-temperature environments?
The listed operating temperature range is -40°C to +90°C, so the temperature specification is broad. No IP rating is provided in the listed specs, so outdoor exposure or wet-location suitability is not defined by this product data.
