Mean Well DETN01N-12 DC-DC Converter - 1W - 21.6~26.4V in ±12V out
The DETN01N is a 1W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating1 Watt
-
Output Voltage12 Volt
-
Rated Current0.04 Ampere
-
Input Voltage21.6V~26.4V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN01N-12 for a low-power 12V analog or signal-conditioning circuit in industrial equipment?
Yes, it is a constant-voltage 12V converter rated at 1W, which fits low-power analog, monitoring, or signal-conditioning functions. The source feeding it should be within the listed 21-26VAC input range.
Is the DETN01N-12 a good fit for embedded control boards that need a small 12V rail?
It can be a fit for embedded boards that need a regulated 12V output and have low power demand. With a 1W rating and 0.04A output current, it is better for small support circuitry than for larger control loads.
Can this converter be used in automation or instrumentation products with a 24V-class input?
It is intended for applications where the available input falls within 21-26VAC and the required output is constant-voltage 12V. That makes it a practical option for compact, low-power automation or instrumentation sections rather than high-draw devices.
What is the difference between DETN01N-12, DETN01N-05, and DETN01N-15?
These three models share the same 1W power rating, 21-26VAC input range, 15.24 × 10.9 × 7.1 mm size, -40°C to +90°C operating range, and 3-year warranty. Their outputs differ: DETN01N-05 is 5V at 100A, DETN01N-12 is 12V at 0.04A, and DETN01N-15 is 15V at 0.03A.
Can the DETN01N-12 be used in outdoor equipment or wide-temperature enclosures?
Its listed operating temperature range is -40°C to +90°C, so it is specified for wide temperature conditions. No IP rating is listed, so the product data does not define direct outdoor or washdown suitability.
