Mean Well DETN01N-15 DC-DC Converter - 1W - 21.6~26.4V in ±15V out
The DETN01N is a 1W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: UL62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating1 Watt
-
Output Voltage15 Volt
-
Rated Current0.03 Ampere
-
Input Voltage21.6V~26.4V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCB,CE,EMC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN01N-15 for low-power 15V analog circuitry in industrial or test equipment?
Yes, it is aimed at low-power circuits that need constant-voltage 15V output from a 21-26VAC input range. With a 1W rating, it is better suited to small analog, measurement, or support functions than to larger loads.
Is the DETN01N-15 suitable for embedded instrumentation modules that require 15V?
It can be used where the module needs a compact 15V rail and only modest output power. The listed output is 15V at 0.03A with 1W rated power, so it fits low-power instrumentation sections rather than higher-current equipment.
Can this converter support a compact automation board that runs from a 24V-class source and needs 15V output?
It is designed for inputs in the stated 21-26VAC range and provides constant-voltage 15V output. Its 15.24 × 10.9 × 7.1 mm size also makes it appropriate where board area is limited and the power requirement stays within 1W.
How does the DETN01N-15 compare with the DETN01N-05 and DETN01N-12 versions?
All three are 1W models in the same series and share the 21-26VAC input range, 15.24 × 10.9 × 7.1 mm dimensions, -40°C to +90°C operating range, and 3-year warranty. The output options are 5V at 100A for DETN01N-05, 12V at 0.04A for DETN01N-12, and 15V at 0.03A for DETN01N-15.
Is the DETN01N-15 rated for outdoor use or harsh ambient temperatures?
The temperature specification is -40°C to +90°C, which supports wide operating conditions from a temperature standpoint. No IP rating is shown in the provided specs, so outdoor exposure suitability is not defined here.
