Mean Well DETN02M-05 DC-DC Converter - 2W - 10.8~13.2V in ±5V out
The DETN02M is a 2W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating2 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~100°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN02M-05 to generate a 5V rail inside a 12V industrial control board?
Yes, this model is intended for low-power constant-voltage conversion in equipment that needs a 5V output from a 10.8~13.2V input range. Its 2W rating makes it a fit for small control, interface, and signal-conditioning sections rather than larger loads.
Is the DETN02M-05 suitable for embedded electronics in a vehicle or battery-based 12V system?
It can fit embedded designs that operate from a nominal 12V source, because the listed input range is 10.8~13.2V. The 5V constant-voltage output and 2W power level make it better suited to compact electronic circuits than higher-power subsystems.
Can this converter be used for low-power automation sensors or logic circuits that need 5V?
Yes, it is appropriate where a stable 5V output is needed in a small automation or monitoring circuit. The 2W capacity and compact 15.24 × 10.9 × 7.1 mm package are aligned with tightly packed, low-power designs.
Is the DETN02M-05 suitable for outdoor or harsh exposed environments?
The operating temperature range is -40°C to +100°C, which supports use across a wide temperature span. However, no IP rating is listed, so it is better treated as a board-level part for protected indoor equipment or enclosed systems rather than exposed outdoor use.
How does the DETN02M-05 compare with the other DETN02M series options?
Within this series, the DETN02M-05 is rated 2W with a 5V output, while the DETN02M-12 is 2W with 12V at 0.08A and the DETN02M-15 is 2W with 15V at 0.07A. All three share the same 15.24 × 10.9 × 7.1 mm dimensions, 0.0012 kg weight, and -40°C to +100°C operating temperature range.
