Mean Well DETN02M-12 DC-DC Converter - 2W - 10.8~13.2V in ±12V out
The DETN02M is a 2W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating2 Watt
-
Output Voltage12 Volt
-
Rated Current0.08 Ampere
-
Input Voltage10.8V~13.2V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~100°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN02M-12 to provide 12V for analog or interface circuitry inside industrial equipment?
Yes, this converter is a fit for low-power internal circuits that need a regulated 12V output from a 10.8~13.2V input range. With a 2W rating, it is intended for small electronic sections rather than larger field loads.
Is the DETN02M-12 appropriate for embedded measurement or signal-conditioning modules that need 12V?
It is well suited to embedded designs where a constant 12V rail is needed at a modest power level. The 2W output and 0.08A rating make it a better match for compact instrumentation or conditioning stages than power-hungry devices.
Can this model be used in compact automation electronics where board space is limited?
Yes, its 15.24 × 10.9 × 7.1 mm size and 0.0012 kg weight support dense board layouts and compact assemblies. It is intended for low-power DC-DC conversion in tightly integrated control or monitoring hardware.
Can the DETN02M-12 be used in equipment exposed to wide temperature swings?
The specified operating range is -40°C to +100°C, so it is designed for electronics that may face substantial temperature variation. Because no IP rating is listed, it should be used in protected housings or indoor equipment rather than directly exposed outdoor environments.
What is the difference between the DETN02M-12 and the other models in the same series?
The DETN02M-12 is the 12V version at 2W and 0.08A. The DETN02M-05 is 2W with a 5V output, and the DETN02M-15 is 2W with a 15V output at 0.07A; all share the same 15.24 × 10.9 × 7.1 mm dimensions, 0.0012 kg weight, and -40°C to +100°C operating range.
