Mean Well DETN02N-05 DC-DC Converter - 2W - 21.6~26.4V in ±5V out
The DETN02N is a 2W Mean Well. power converter. and an input range of 4.5~5.5Vdc.
Key Features
- ✓ Input voltage range: 4.5~5.5Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDENT Series
-
Power Rating2 Watt
-
Output Voltage5 Volt
-
Rated Current0.2 Ampere
-
Input Voltage21.6V~26.4V
-
No of Output2
-
Dimming ControlNone
-
Standards MetCE,EMC
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~100°C
-
Warranty3 Year
-
Length0.6 in
-
Width0.43 in
-
Height0.28 in
-
Weight0 lb
::specification::
Frequently Asked Questions
Can I use the DETN02N-05 to power a 5V microcontroller board inside industrial equipment?
It can be used for embedded or control electronics that need a 5V constant-voltage output and stay within the converter's 2W power rating. It is intended for systems with a 21-26VAC input and operates across -40°C to +100°C.
Is this 5V converter suitable for low-power sensor or interface circuits in automation panels?
Yes, it fits low-power 5V sensor, interface, or logic circuits where a constant 5V output is required and the total load stays within 2W. Its compact 15.24 × 10.9 × 7.1 mm size also suits dense control hardware.
Can the DETN02N-05 be used in compact embedded devices with limited board space?
This model is designed for space-constrained electronics, with dimensions of 15.24 × 10.9 × 7.1 mm and a weight of 0.0012 kg. It is appropriate for compact embedded designs that need 5V output from a 21-26VAC input source.
Is the DETN02N-05 suitable for outdoor or harsh-temperature applications?
The listed operating temperature range is -40°C to +100°C, which supports use in very cold and very hot environments. No IP rating is provided in the listed specs, so outdoor or washdown suitability should not be assumed from this data alone.
What is the difference between the DETN02N-05, DETN02N-12, and DETN02N-15?
All three models are 2W DC-DC converters in the same series. The DETN02N-05 provides 5V output at 0.2A, the DETN02N-12 provides 12V output at 0.08A, and the DETN02N-15 provides 15V output at 0.07A.
