Mean Well SI06W8-03 8:1 Ultra-Wide Input DC-DC Regulated Converter,...
The DI06W8 is a 6W Mean Well. power converter. and an input range of 9~75Vdc.
Key Features
- ✓ Input voltage range: 9~75Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Wide operating temperature: -40~+90℃
- ✓ Protections: Short circuit / Overload / Over voltage / Under voltage
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDI06W8 Series
-
Power Rating6 Watt
-
Output Voltage3.3 Volt
-
Rated Current0.00 Ampere
-
Input Voltage9V~75V
-
No of Output1
-
Standards MetCB,CE,EAC
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty3 Year
-
Length1 in
-
Width1 in
-
Height0.4 in
-
Weight0.04 lb
::specification::
Frequently Asked Questions
What is the Mean Well SI06W8-03 designed for?
The Mean Well SI06W8-03 is a regulated DC-DC converter intended for applications that need a stable 3.3V DC output from a very wide DC input range. Its 6W power rating and compact DIP 1 inch by 1 inch package make it suitable for space-constrained industrial and embedded equipment.
What makes the SI06W8-03 different from standard DC-DC converters?
This model stands out for its 8:1 ultra-wide input range, which gives designers more flexibility when input voltage can vary across systems or platforms. It also combines that range with regulated single-output 3.3V performance, up to 86% efficiency, and 3KVDC input-to-output isolation.
What are the key electrical specifications of the SI06W8-03?
The SI06W8-03 is a single-output regulated DC-DC converter rated for 6W with a 3.3V DC output. It features an 8:1 ultra-wide input range, up to 86% efficiency, and 3KVDC input-to-output isolation.
Can the SI06W8-03 operate in demanding temperature conditions?
Yes. This converter is specified for operation from -40°C to +90°C, which makes it suitable for equipment exposed to both low and elevated ambient temperatures. Buyers should still confirm that the full system design stays within the product's rated operating conditions.
Does the SI06W8-03 include built-in protection features?
Yes. Mean Well specifies protection for short circuit, overload, over temperature, over voltage, and input under voltage on this model. These protections can help improve resilience in industrial and OEM applications where power stability and fault tolerance matter.
Is the SI06W8-03 suitable for noise-sensitive or compliance-focused equipment?
It can be a strong fit for designs where EMC performance is important because it complies with BS EN/EN55032 radiated Class A without additional components. That can simplify product selection for commercial or industrial systems that need a compact isolated converter with solid baseline emissions performance.
Does the SI06W8-03 require a minimum load to regulate properly?
No. Mean Well lists this model as requiring no minimum load, which can be useful in systems where load conditions vary or may be very light during standby operation. That gives more flexibility than converters that only perform correctly above a defined minimum load.
What warranty is offered for the SI06W8-03?
The SI06W8-03 includes a 3-year warranty from Mean Well. For B2B buyers, that can be helpful when evaluating lifecycle support and supplier reliability for repeat-use designs.
