Mean Well DKM30G-12N 2"x1" Package DC-DC Converter 30W 12...
The DKM30G is a 30W Mean Well. power converter. and an input range of 9~36Vdc.
Key Features
- ✓ Input voltage range: 9~36Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 020/2011
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDKM30-N Series
-
Power Rating30 Watt
-
Output Voltage12 Volt
-
Rated Current1.25 Ampere
-
No of Output1
-
Standards MetCB,CE,EAC
-
Operation ModeConstant Current
-
Warranty3 Year
-
Length2 in
-
Width1 in
-
Height0.44 in
-
Weight0.07 lb
::specification::
Frequently Asked Questions
What are the main output specifications of the Mean Well DKM30G-12N?
The DKM30G-12N is a 30W single-output DC-DC converter with a 12V DC output. Its rated output current is 1.25A. This model is designed as a compact modular converter in a 2"x1" package.
Does the DKM30G-12N support a wide input range?
Yes. This model has a 4:1 ultrawide input range, which gives more flexibility than converters with narrower input windows. That makes it easier to use in systems where the available DC input can vary within a broad range.
Can the Mean Well DKM30G-12N operate in demanding temperature conditions?
This converter is rated for operation from -40°C to +90°C. Mean Well also specifies no derating from -40°C to +60°C. That makes it a practical option for equipment exposed to both cold-start and elevated ambient conditions.
What protection features are included in the DKM30G-12N?
The DKM30G-12N includes protection for short circuit, overload, over temperature, and over voltage. Short-circuit protection is specified as continuous. It also provides 3KVDC input-to-output isolation for added electrical separation.
Does this DC-DC converter require a minimum load to regulate properly?
No. Mean Well specifies that the DKM30G-12N does not require a minimum load. That can simplify product selection for designs where the output demand may be light or variable.
Does the DKM30G-12N offer any control or adjustment features?
Yes. This model supports remote ON/OFF control and output trimming of plus or minus 10%. Those features can be useful when tighter output adjustment or remote power control is needed at the system level.
What efficiency and warranty does the Mean Well DKM30G-12N provide?
The DKM30G-12N has efficiency up to 89%, which helps reduce wasted power and heat in compact designs. Mean Well lists this model with a 3-year warranty. For buyers comparing 30W modular converters, those are meaningful indicators of long-term value.
