Mean Well DKM30G-15N 2"x1" Package DC-DC Converter 30W 15...
The DKM30G is a 30W Mean Well. power converter. and an input range of 9~36Vdc.
Key Features
- ✓ Input voltage range: 9~36Vdc
- ✓ 3KVDC reinforced I/O isolation
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Remote ON/OFF control
- ✓ Safety approvals: EAC TP TC 020/2011
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesDKM30-N Series
-
Power Rating30 Watt
-
Output Voltage15 Volt
-
Rated Current1 Ampere
-
No of Output1
-
Standards MetCB,CE,EAC
-
Operation ModeConstant Current
-
Warranty3 Year
-
Length2 in
-
Width1 in
-
Height0.44 in
-
Weight0.07 lb
::specification::
Frequently Asked Questions
What is the Mean Well DKM30G-15N designed for?
The Mean Well DKM30G-15N is a 30W DC-DC converter that provides a single 15V output. It is suited to embedded and industrial power applications that need DC voltage conversion in a compact 2"x1" package. This model is typically chosen where board space is limited and stable regulated output is important.
What are the main electrical specifications of the DKM30G-15N?
This model is rated for 30W total output power and delivers a single 15V DC output. Its rated output current is 1A. Mean Well also specifies up to 89% efficiency for this converter.
Is the DKM30G-15N suitable for demanding temperature environments?
Yes, the DKM30G-15N is specified for operation from -40°C to +90°C. Mean Well states it can run from -40°C to 60°C without derating. That makes it a practical option for equipment exposed to both low and elevated ambient temperatures.
What protection features are included in the DKM30G-15N?
The DKM30G-15N includes protection for short circuit, overload, over temperature, and over voltage conditions. It also provides 3KVDC input-to-output isolation. These features help support reliability in industrial and OEM applications.
Does the DKM30G-15N require a minimum load to regulate properly?
No, this model does not require a minimum load. That can be useful in systems where load conditions vary or where the converter may spend time under light-load operation. It gives more flexibility than converters that need a minimum output demand.
Does the DKM30G-15N support control or adjustment features?
Yes, the DKM30G-15N supports remote ON/OFF control and output trimming of ±10%. These features can be useful in systems that need controlled power management or minor output adjustment within the specified range. The product is also built in an industry-standard 2"x1" DIP package format.
What warranty is provided with the DKM30G-15N?
Mean Well provides a 3-year warranty for the DKM30G-15N. For B2B buyers, that adds confidence for use in commercial and industrial equipment. It aligns with the product's positioning as a compact, protected DC-DC converter for long-term service.
