Mean Well ELGC-300-L-A Power Supply 300W 1400mA - Adjustable
The ELGC-300-L is a 300W Mean Well power converter (input range: 100~305VAC).
Key Features
- ✓ Input voltage range: 100~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: DALI STANDARDS
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesELGC-L Series
-
Power Rating301 Watt
-
Output Voltage240 Volt
-
Rated Current1.4 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming ControlBuilt-in Potentiometer
-
Standards MetCB,CCC,CE,EAC,ENEC,KC,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length9.69 in
-
Width3.03 in
-
Height1.56 in
-
Weight3.2 lb
::specification::
Frequently Asked Questions
Can I use the ELGC-300-L-A for LED downlights with long series LED strings?
Yes, if the downlight is designed for 1400mA constant current and the total LED load falls within the 116-232V CC range. This model is intended for constant current LED loads, not constant voltage products.
Is this driver suitable for signage modules that use a higher-voltage constant current array?
It can be suitable for signage systems built around a 1400mA constant current LED array with total forward voltage between 116V and 232V. It is not intended for standard constant voltage signage modules that expect a fixed DC voltage output.
Can the ELGC-300-L-A run a small LED array with a high total forward voltage?
Yes, as long as the array is specified for 1400mA constant current and operates within the 116-232V constant current range. The exact number of LEDs depends on the forward voltage of each LED, so the load must be checked by total voltage rather than LED count.
How should I check compatibility for this 1400mA constant current driver?
The LED load must require 1400mA constant current and have a combined forward voltage within 116-232V. The number of LEDs will vary based on each LED forward voltage, so there is no single fixed LED quantity for this driver.
Can this driver be used in damp or semi-protected locations?
Yes, it is rated IP65, which is suitable for water-resistant use where full submersion protection is not required. It also carries an operating temperature range of -40°C to +85°C for demanding conditions.
