Mean Well EPS-120-15 Power Supply 84W 15V
The EPS-120 is a 120W Mean Well DIN rail power converter with a 101.6mm profile (input range: 80~264VAC, operating temperature: -30~+70℃).
Key Features
- ✓ 101.6mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 80~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Safety approvals: UL62368-1, TUV EN62368-1, IEC62368-1, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesEPS Series
-
Power Rating84 Watt
-
Output Voltage15 Volt
-
Rated Current5.6 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length4 in
-
Width2 in
-
Height1.14 in
-
Weight0.33 lb
::specification::
Frequently Asked Questions
Can I use the EPS-120-15 for 15V industrial electronics?
Yes, if the equipment specifically requires a 15V constant voltage input. This model delivers 15V output with up to 5.6A and 84W available.
Is the EPS-120-15 a good fit for 15V test and measurement equipment?
It can be used for test, measurement, or control hardware that is designed for 15V DC operation. The output capability is 15V at 5.6A, so the total load should remain within 84W.
Can this 15V power supply support embedded boards and interface modules?
It is suitable for embedded or industrial modules that need a regulated 15V source rather than 12V or 24V. The power envelope is 84W total at 15V, with a maximum output current of 5.6A.
Is the EPS-120-15 meant for indoor or outdoor conditions?
The specs show an operating temperature range of -30°C to +70°C, which gives a defined thermal range. However, no IP rating is listed, so the provided data does not establish weather, dust, or water resistance for outdoor exposure.
How does the EPS-120-15 compare with the other EPS-120 models?
In the EPS-120 group, the options are 12V at 84W and 7A, 15V at 84W and 5.6A, 24V at 84W and 3.5A, 27V at 85W and 3.15A, and 48V at 84W and 1.75A. This 15V version keeps the same compact 101.6 x 50.8 x 29.0 mm form factor while changing the output voltage and available current.
