Mean Well HLG-60H-36AB Power Supply 60W 36V - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HLG-60H-36AB Power Supply 60W 36V - Adjustable and Dimmable
The HLG-60H is a 60W Mean Well power converter (input range: 90~305VAC).
Key Features
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.8 SAFETY &
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHLG Series
-
Power Rating60 Watt
-
Output Voltage36 Volt
-
Rated Current1.7 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetCB,CCC,CE,EAC,PSE,RCM,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~80°C
-
Warranty7 Year
-
Length6.73 in
-
Width2.42 in
-
Height1.45 in
-
Weight1.61 lb
::specification::
Frequently Asked Questions
Can I use the HLG-60H-36AB to power dimmable 36V LED strip in a commercial display?
Yes. The HLG-60H-36AB delivers 60W at 36V with both output adjustment and 1-10V/PWM dimming input. You can fine-tune the voltage to match your strip's requirements and control brightness through a compatible dimmer, ideal for retail displays, gallery lighting, or hospitality accent lighting.
Is the HLG-60H-36AB suitable for 36V LED signage that needs scheduled dimming?
Yes. The built-in 1-10V/PWM dimming input can be driven by a timer or smart controller to reduce sign brightness during nighttime hours. At 60W and 36V with a CC range of 21-36V, it handles typical small-format sign modules while providing full dimming flexibility.
Can the HLG-60H-36AB drive 36V architectural LED fixtures with tunable output?
Yes. The adjustable output lets you set the precise voltage and current via built-in potentiometers, while the dimming input provides real-time brightness control. This dual adjustment capability suits architectural fixtures where both calibration and scene-setting are required.
How many meters of 36V LED strip can the HLG-60H-36AB power?
Divide 60W by your strip's rated power per meter. A 36V strip drawing 12W/m allows up to 5 meters (60W / 12W per meter = 5m). A strip at 7.5W/m allows 8 meters. Always verify your strip's rated power per meter and ensure the total stays within 60W.
Can the HLG-60H-36AB be installed in a covered outdoor location like a gazebo?
Yes. With an IP65 rating, it is protected against low-pressure water jets and dust ingress, so a gazebo, covered deck, or similar sheltered outdoor spot is appropriate. For fully exposed locations subject to submersion or heavy downpours, the IP67-rated HLG-60H-36B offers stronger water protection.
What are the differences between the HLG-60H-36, 36A, 36AB, and 36B variants?
All share 60W / 36V / 1.7A core specs and a CC range of 21-36V. The base HLG-60H-36 has fixed output and IP67 waterproofing. The -36A adds potentiometer adjustment for voltage and current (IP65). The -36AB adds both adjustment and 1-10V/PWM dimming (IP65). The -36B has dimming only and retains IP67.
