Mean Well HLG-80H-36AB Power Supply 80W 36V - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HLG-80H-36AB Power Supply 80W 36V - Adjustable and Dimmable
The HLG-80H is a 80W Mean Well power converter (input range: 90~305VAC).
Key Features
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.8 SAFETY &
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHLG Series
-
Power Rating80 Watt
-
Output Voltage36 Volt
-
Rated Current2.3 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Dimming Control10V PWM,1-10V,Built-in Potentiometer,Resistance
-
Standards MetCB,CCC,CE,EAC,PSE,RCM,TUV,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~80°C
-
Warranty7 Year
-
Length7.7 in
-
Width2.42 in
-
Height1.53 in
-
Weight1.85 lb
::specification::
Frequently Asked Questions
Can I use the HLG-80H-36AB to power 36V LED strip lighting in a sheltered outdoor area?
Yes. The HLG-80H-36AB outputs 36V at up to 2.3A (80W) and carries an IP65 water-resistant rating, making it suitable for covered patios, soffits, and canopy installations where dust and splashing water are present. For fully exposed rain locations, consider the IP67-rated HLG-80H-36B instead.
Is the HLG-80H-36AB a good driver for dimmable 36V LED signage?
Yes. The HLG-80H-36AB includes both a built-in potentiometer for output adjustment and a 1-10V/PWM dimming input, so you can fine-tune brightness for 36V channel letters or light boxes. Its 80W capacity and wide 90-305VAC input handle most commercial mains supplies.
Can I dim 36V LED panel lights with the HLG-80H-36AB using a 1-10V controller?
Yes. The AB suffix means this model accepts 1-10V and PWM dimming signals, allowing smooth brightness control of 36V LED panels. The adjustable output also lets you trim voltage and current via the built-in potentiometer to match your panel's exact requirements within the 21-36V CC range.
How many meters of 36V LED strip can the HLG-80H-36AB power?
Divide 80W by your strip's rated power per meter. For example, a strip drawing 8W/m would allow up to 10 meters (80W / 8W per meter = 10m). Always check your strip's rated power per meter and keep the total load at or below 80W.
What is the difference between the HLG-80H-36, 36A, 36AB, and 36B models?
All four share the same 80W / 36V / 2.3A core specs and CC voltage range of 21-36V. The base HLG-80H-36 has no adjustment or dimming and is IP67 waterproof. The -36A adds output adjustment via potentiometer (IP65). The -36AB adds both adjustment and 1-10V/PWM dimming (IP65). The -36B adds dimming input only and retains IP67.
Can I mount the HLG-80H-36AB in a dusty industrial environment?
Yes. Its IP65 rating means the enclosure is fully protected against dust ingress and low-pressure water jets. The aluminium casing and -40°C to +80°C operating range also handle temperature extremes found in factories, workshops, and warehouses.
