Mean Well HEP-100-15 Power Supply 100.05W 15V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HEP-100-15 Power Supply 100.05W 15V
The HEP-100 is a 100W Mean Well DIN rail power converter with a 220mm profile (input range: 90~305VAC, operating temperature: -55~+70℃).
Key Features
- ✓ 220mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -55~+70℃
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.6,9 UL62368-1 , IEC/EN62368-1,IP65 (or IP68 for HEP-100 Blank type) , EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHEP Series
-
Power Rating100.05 Watt
-
Output Voltage15 Volt
-
Rated Current6.67 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~70°C
-
Warranty6 Year
-
Length8.66 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.47 lb
::specification::
Frequently Asked Questions
Can I use the HEP-100-15 for 15V industrial instrumentation or sensor systems?
Yes, if the equipment requires constant 15V DC and the total load stays within 6.67A and 100.05W. That makes it suitable for industrial instrumentation, sensing, and control devices designed for 15V input.
Is this a good fit for a 15V embedded test bench or electronics development station?
It can be used for 15V embedded boards, test fixtures, and lab devices that need regulated constant-voltage output up to 6.67A. The 100.05W rating defines the total available output budget for the connected 15V load.
Can the HEP-100-15 power 15V automation modules in a harsh industrial setting?
Yes, if those 15V modules stay within 6.67A and 100.05W combined. The supply is rated for -55°C to +70°C operation, uses a fanless design, and is built to withstand 10G vibration.
Is this model suitable for outdoor or washdown-prone locations?
Yes, this version is rated IP68 and operates from -55°C to +70°C, so it is better suited to environments where stronger ingress protection is needed. That makes it appropriate for harsh indoor areas and outdoor locations where exposure is a concern.
How does the HEP-100-15 compare with other HEP-100 models?
Within the HEP-100 group, the 12V models are 100.08W and 8.34A, the 15V models are 100.05W and 6.67A, the 24V models are 96W and 4A, the 36V models are 95.4W and 2.65A, the 48V models are 96W and 2A, and the 54V models are 95.58W and 1.77A. The main difference is the output voltage and the matching current available at roughly the same power class.
