Mean Well HEP-185-15 Power Supply 172W 15V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HEP-185-15 Power Supply 172W 15V
The HEP-185 is a 185W Mean Well DIN rail power converter with a 228mm profile (input range: 90~305VAC).
Key Features
- ✓ 228mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.6,9 UL62368-1, IECIEN62368-1, IP65 (or IP68 for HEP-185 Blank type), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHEP Series
-
Power Rating172 Watt
-
Output Voltage15 Volt
-
Rated Current11.5 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~70°C
-
Warranty6 Year
-
Length8.98 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.54 lb
::specification::
Frequently Asked Questions
Can I use the HEP-185-15 for a 15V industrial automation or control device?
Yes, this model provides a constant 15V output rated for 172W and 11.5A. It is appropriate for equipment that specifically requires 15V DC and remains within those output limits.
Is the HEP-185-15 suitable for 15V embedded systems in harsh environments?
It is built for harsh conditions with a fanless design, rugged metal case, and 10G vibration resistance. The operating temperature range of -55°C to +70°C supports embedded or control equipment in very cold or very hot locations.
Can this power supply be used for 15V instrumentation or monitoring equipment outdoors?
Yes, this version is specified as IP68, which makes it suitable where a more sealed enclosure is needed. It also supports a wide 90-305VAC input range and operation from -55°C to +70°C.
Would the HEP-185-15 work for a continuous-duty 15V DC load in an enclosed cabinet?
It can, provided the load stays within 172W and 11.5A at 15V. The fanless design and efficiency up to 96% are useful in enclosed equipment where reduced maintenance and heat are important.
How does the HEP-185-15 compare with other 15V models in the HEP family?
For 15V versions, the HEP-100-15 and HEP-100-15A are 100.05W at 6.67A, the HEP-150-15 and HEP-150-15A are 150W at 10A, this HEP-185-15 and the HEP-185-15A are 172W at 11.5A, the HEP-240-15 and HEP-240-15A are 225W at 15A, the HEP-320-15 and HEP-320-15A are 285W at 19A, and the HEP-600-15 and HEP-600-15A are 540W at 36A. The series also includes a different 14.4V model, the HEP-600C-12, rated for 600W and 35A.
