Mean Well HEP-185-36 Power Supply 187.2W 36V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well HEP-185-36 Power Supply 187.2W 36V
The HEP-185 is a 185W Mean Well DIN rail power converter with a 228mm profile (input range: 90~305VAC).
Key Features
- ✓ 228mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 90~305VAC
- ✓ Cooling by free air convection
- ✓ Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: Note.6,9 UL62368-1, IECIEN62368-1, IP65 (or IP68 for HEP-185 Blank type), EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHEP Series
-
Power Rating187.2 Watt
-
Output Voltage36 Volt
-
Rated Current5.2 Ampere
-
Input Voltage90V~305V
-
No of Output1
-
Standards MetCB,CE,EAC,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-55°C~70°C
-
Warranty6 Year
-
Length8.98 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.54 lb
::specification::
Frequently Asked Questions
Can I use the HEP-185-36 for 36V industrial automation or motion-control equipment?
Yes, this model provides 36V constant voltage at up to 5.2A, with a total output rating of 187.2W. That makes it suitable for 36V industrial and embedded equipment designed for a fixed 36VDC supply. The wide 90-305VAC input also supports use across varied facility power conditions.
Is the HEP-185-36 appropriate for 36V LED lighting or display systems in harsh environments?
It can be used for 36V constant-voltage lighting or display loads as long as the total draw stays within 187.2W and 5.2A. Because this version is rated IP68 and operates from -55°C to +70°C, it is positioned for harsher indoor or outdoor conditions than a standard indoor supply. The fanless design also helps in sealed or dirty environments.
Can the HEP-185-36 power 36V embedded electronics or industrial sensors from a single AC source?
It is intended for 36VDC loads that need a constant-voltage source and fit within 5.2A and 187.2W. The 90-305VAC input allows one model to be used across a broad AC input range. That makes it practical for 36V embedded or automation systems with consistent DC bus requirements.
Is the HEP-185-36 suitable for outdoor enclosures or exposed industrial locations?
Yes, this is the IP68 version, so it is the more sealed option in the HEP-185-36 pair. It is also rated for -55°C to +70°C operation and uses a rugged metal case built for harsh environments. Those specs make it a strong fit for exposed or demanding locations when a sealed 36V supply is needed.
How does the HEP-185-36 compare with other HEP-185 voltage variants?
In the HEP-185 family, the choices are 156W at 12V and 13A, 172W at 15V and 11.5A, 187.2W at 24V and 7.8A, 187.2W at 36V and 5.2A, 187.2W at 48V and 3.9A, and 186.3W at 54V and 3.45A. The HEP-185-36 and HEP-185-36A share the same 187.2W, 36V, and 5.2A electrical rating. The main difference is choosing the output voltage that matches the load, while this version is the IP68 model.
