Mean Well HRP-100-12 Power Supply 102W 12V
The HRP-100 is a 100W Mean Well DIN rail power converter with a 159mm profile (input range: 85~264VAC).
Key Features
- ✓ 159mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 85~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Remote ON/OFF control
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHRP Series
-
Power Rating102 Watt
-
Output Voltage12 Volt
-
Rated Current8.5 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-40°C~60°C
-
Warranty5 Year
-
Length6.26 in
-
Width3.82 in
-
Height1.5 in
-
Weight1.23 lb
::specification::
Frequently Asked Questions
Can I use the HRP-100-12 for a 12V industrial control panel?
Yes, if the panel uses a 12V constant-voltage bus and stays within 102W and 8.5A total demand. Its 85-264VAC input also fits facilities that need wide AC input tolerance.
Is the HRP-100-12 suitable for 12V access control or security hardware?
It can fit 12V access control or security hardware when the combined load remains within 12V, 8.5A, and 102W. This is a constant-voltage power supply, so it is intended for equipment designed for a fixed 12V supply.
Can this 12V power supply run embedded computers, displays, or network appliances that need 12V DC?
It is suitable for 12V embedded or IT hardware when the equipment requires constant 12V output and the total draw does not exceed 8.5A or 102W. The wide 85-264VAC input helps when the same design may be used across different AC input environments.
Is the HRP-100-12 okay for indoor equipment in hot or cold industrial areas?
The specified operating temperature range is -40°C to +60°C, which supports demanding indoor industrial environments. No IP rating is listed in the provided specs, so these specs alone do not establish suitability for exposed outdoor locations.
How does the HRP-100-12 compare with the other HRP-100 voltage options?
Within the listed HRP-100 models, the outputs are 3.3V 20A 66W, 5V 17A 85W, 7.5V 13.5A 101.3W, 12V 8.5A 102W, 15V 7A 105W, 24V 4.5A 108W, 36V 2.9A 104.4W, and 48V 2.2A 105.6W. The source list also includes HRP-1000N3-12, HRP-1000N3-24, HRP-1000N3-36, and HRP-1000N3-48 part numbers, but no wattage or current figures are provided here for those models.
