Mean Well IRM-01-24 Switching Power Supply 1W 24V 42mA - Encapsulated
The IRM-01 is a 1W Mean Well power converter (input range: 85~305VAC).
Key Features
- ✓ Input voltage range: 85~305VAC
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesIRM Series
-
Power Rating1 Watt
-
Output Voltage24 Volt
-
Rated Current0.04 Ampere
-
Input Voltage85V~305V
-
No of Output1
-
Dimming ControlNone
-
Standards MetBSMI,CB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~85°C
-
Warranty3 Year
-
Length1.33 in
-
Width0.87 in
-
Height0.59 in
-
Weight0.05 lb
::specification::
Frequently Asked Questions
Can I use the IRM-01-24 for a small 24V PLC or automation interface circuit?
Yes, if the interface circuit needs constant 24V DC and stays within the 1W, 0.04A output limit. It is intended for very low-power 24V control or signaling electronics rather than standard higher-current 24V automation loads.
Is the IRM-01-24 suitable for a low-power industrial sensor or monitoring node?
It can be suitable for a compact 24V monitoring or sensor node when the total current stays at or below 0.04A. The miniature encapsulated form factor at 33.7 × 22.2 × 15.0 mm also supports board-level industrial electronics.
Can this model power a light 24V embedded I/O or relay logic board?
It can for very small 24V embedded I/O or relay logic circuits that fit within the 1W rating. Buyers should treat it as a constant voltage supply for low-draw board functions, not as a general-purpose 24V power source.
How does IRM-01-24 compare with other low-power IRM outputs?
At the 1W level, the IRM-01 family is available in 3.3V 300A, 5V 200A, 9V 111A, 12V 0.08A, 15V 0.07A, and 24V 0.04A, and every one also has an S version. If the project still needs 24V but more output than 1W 0.04A, the broader IRM range also offers 2W 0.08A, 3W 125A, 5.52W 0.23A, 10.08W 0.42A, 15.12W 0.63A, 21.6W 0.9A, 31.2W 1.3A, 45.6W 1.9A, 60W 2.5A, and 90W 3.75A versions.
Is the IRM-01-24 appropriate for outdoor equipment or wide-temperature installations?
The operating temperature range is -30°C to +85°C, which supports a broad temperature window. The provided specifications do not list an IP rating, so outdoor or washdown suitability is not stated.
