Mean Well ISI-501-212B True Sine Wave DC-AC Inverter 450W 110V out 12V in with MPPT Solar Charger
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ISI-501-212B True Sine Wave DC-AC Inverter 450W 110V out ...
The ISI-501 is a 500W Mean Well power converter (input range: 35~50V).
Key Features
- ✓ Input voltage range: 35~50V
- ✓ Protections: Over temperature / Reverse polarity
- ✓ Remote ON/OFF control
- ✓ Safety approvals: IEC62368-1 CB, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesISI Series
-
Power Rating450 Watt
-
Output Voltage230 Volt
-
Input Voltage10.5V~15V
-
No of Output1
-
Standards MetCB,CE,cUL,E13,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~40°C
-
Warranty3 Year
-
Length8.07 in
-
Width6.22 in
-
Height2.64 in
-
Weight5.18 lb
::specification::
Frequently Asked Questions
What is the Mean Well ISI-501-212B designed for?
The ISI-501-212B is a true sine wave DC-AC inverter for converting 12V DC input power to 110V AC output. It is intended for applications that need cleaner AC power and also includes a built-in 500W MPPT solar charger for battery-based systems.
What are the main output and input ratings of this inverter?
This model is rated for 450W continuous power and supports up to 1000W surge power. Its DC input range is 10.5 to 15VDC, which matches 12V battery-based systems.
How clean is the AC output from the ISI-501-212B?
This inverter provides a true sine wave output with total harmonic distortion below 3%. That makes it a better fit than modified sine wave designs for loads that need smoother AC power quality.
Does this model include a solar charger?
Yes. The ISI-501-212B has a built-in 500W MPPT solar charger with typical MPPT efficiency of 98%, which helps improve solar charging performance in battery-based power systems.
What battery types is the ISI-501-212B compatible with?
According to the provided specification, this model is compatible with open and sealed lead-acid batteries. That makes it suitable for systems built around those battery chemistries.
What protection features are built into this inverter?
The ISI-501-212B includes battery low alarm, battery low shutdown, over voltage, over temperature, output short, input polarity reverse, and overload protection. For overload, it can handle 110% load for 60 seconds before shutting down output and requiring re-powering to recover.
Can this inverter operate in demanding temperature conditions?
It is rated for operation from -20°C to +40°C at 100% load. The specification also states operation up to 60°C at 50% load, so ambient temperature and load level both matter in hotter environments.
