Mean Well ISI-501-224B True Sine Wave DC-AC Inverter 500W 110V out 12V in with MPPT Solar Charger
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ISI-501-224B True Sine Wave DC-AC Inverter 500W 110V out ...
The ISI-501 is a 500W Mean Well power converter (input range: 35~50V).
Key Features
- ✓ Input voltage range: 35~50V
- ✓ Protections: Over temperature / Reverse polarity
- ✓ Remote ON/OFF control
- ✓ Safety approvals: IEC62368-1 CB, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesISI Series
-
Power Rating500 Watt
-
Output Voltage230 Volt
-
Input Voltage21V~30V
-
No of Output1
-
Standards MetCB,CE,cUL,E13,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~40°C
-
Warranty3 Year
-
Length8.07 in
-
Width6.22 in
-
Height2.64 in
-
Weight5.18 lb
::specification::
Frequently Asked Questions
What is the Mean Well ISI-501-224B designed for?
The ISI-501-224B is a 500W true sine wave DC-AC inverter with a built-in 500W MPPT solar charger. It is intended for applications that need clean AC power from a DC battery-based system while also supporting solar charging in one unit.
What kind of output waveform does this inverter provide?
This model provides a true sine wave AC output with total harmonic distortion below 3%. That makes it a better fit for sensitive electronics and loads that perform best on cleaner power than modified sine wave alternatives.
What DC input range does the ISI-501-224B support?
The specified input voltage range is 21 to 30VDC. Based on that range, this model is intended for 24V-class battery systems rather than 12V systems.
Does this model include a solar charger?
Yes. The ISI-501-224B includes a built-in 500W MPPT solar charger with typical MPPT efficiency of 98%. This combines inversion and solar charging into a single product for battery-based power systems.
How much surge capacity does the inverter have?
This unit is rated for 500W continuous power and supports surge power up to 1000W. The overload specification also states 110% load for 60 seconds before protection engages.
What protections are included in the ISI-501-224B?
This model includes battery low alarm, battery low shutdown, over voltage, over temperature, output short, input polarity reverse, and overload protection. Several fault conditions recover by re-powering the unit after shutdown.
What battery types are supported?
The listed compatible battery types are open and sealed lead-acid batteries. Buyers using other battery chemistries should verify suitability separately, since only lead-acid types are explicitly stated in the provided specifications.
Is the ISI-501-224B suitable for demanding environments?
It is rated for operation from -20°C to +40°C at 100% load, and up to 60°C at 50% load. The unit also uses a thermostatically controlled cooling fan to help manage temperature during operation.
