Mean Well ISI-501-224C True Sine Wave DC-AC Inverter 500W 110V out 12V in with MPPT Solar Charger
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ISI-501-224C True Sine Wave DC-AC Inverter 500W 110V out ...
The ISI-501 is a 500W Mean Well power converter (input range: 35~50V).
Key Features
- ✓ Input voltage range: 35~50V
- ✓ Protections: Over temperature / Reverse polarity
- ✓ Remote ON/OFF control
- ✓ Safety approvals: IEC62368-1 CB, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesISI Series
-
Power Rating500 Watt
-
Output Voltage230 Volt
-
Input Voltage21V~30V
-
No of Output1
-
Standards MetCB,CE,cUL,E13,FCC
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~40°C
-
Warranty3 Year
-
Length8.07 in
-
Width6.22 in
-
Height2.64 in
-
Weight5.18 lb
::specification::
Frequently Asked Questions
What is the Mean Well ISI-501-224C designed for?
The ISI-501-224C is a 500W true sine wave DC-AC inverter for applications that need stable AC output from a 24VDC source. It also includes a built-in 500W MPPT solar charger, which makes it suitable for mobile, off-grid, and backup power systems that use lead-acid batteries.
Does this inverter produce true sine wave output?
Yes. This model provides true sine wave output with total harmonic distortion below 3%, which is important for running sensitive electronics and equipment that perform better on cleaner AC power. That makes it a stronger fit than modified sine wave units for many professional and commercial uses.
What input voltage does the ISI-501-224C require?
This inverter accepts a 24VDC nominal input, with a specified input voltage range of 21 to 30VDC. Buyers should confirm their power system operates within that range during normal use. The product name also identifies it as a 24V input model.
What battery types is this model compatible with?
The ISI-501-224C is specified for open and sealed lead-acid batteries. That makes it appropriate for systems built around common lead-acid battery banks rather than unspecified battery chemistries. Buyers using other battery types should verify suitability before purchase.
What protection features are built into this inverter?
This model includes battery low alarm, battery low shutdown, over voltage, over temperature, output short, input polarity reverse, and overload protection. For overload, over temperature, and output short conditions, the unit shuts down output voltage and requires re-powering to recover. Reverse polarity protection is handled by internal fuse opening.
Can this unit handle startup surges above its continuous rating?
Yes. The ISI-501-224C has a 500W continuous power rating and supports surge power up to 1000W. It also specifies overload performance at 110% load for 60 seconds before protective shutdown.
Is the ISI-501-224C suitable for harsh or variable temperature environments?
It is rated for operation from -20°C to +40°C at 100% load, and up to 60°C at 50% load. The unit also uses a thermostatically controlled cooling fan to support thermal management. Buyers should still evaluate enclosure and ventilation conditions in the final application.
What certifications and warranty does this model include?
The ISI-501-224C is listed as approved to IEC62368-1 CB and EAC TP TC 004, and it meets BS EN/EN62368-1. It also includes a 3-year warranty from the manufacturer. These details can matter for commercial buyers who need documented safety compliance and support coverage.
