Mean Well LDH DC/DC LED Driver CC 1750mA - Step-up - with Wire
The LDH-65 is a Mean Well power converter (input range: 12.5~80VDC).
Key Features
- ✓ Input voltage range: 12.5~80VDC
- ✓ Protections: Short circuit / Over voltage
- ✓ Safety approvals: IEC 61347-1, IEC 61347-2-13, EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesLDH Series
-
Power Rating64.75 Watt
-
Output Voltage37 Volt
-
Rated Current1.75 Ampere
-
Input Voltage9.5V~32V
-
No of Output1
-
Dimming Control0-10V,PWM
-
Standards MetCE,EMC
-
Operation ModeConstant Current
-
Operating Temperature-40°C~60°C
-
Warranty3 Year
-
Length2.95 in
-
Width2.09 in
-
Height0.89 in
-
Weight0.35 lb
::specification::
Frequently Asked Questions
Can I use the LDH-65-1750W for a constant current LED downlight?
Yes, if the downlight requires 1750mA constant current and the LED load operates within the 12-37V CC output range. This 64.75W step-up driver is intended for constant current LED loads, not constant voltage fixtures.
Will the LDH-65-1750W work for LED sign lighting modules?
It can work for sign lighting only when the module is built for 1750mA constant current operation and the total LED forward voltage stays within 12-37V. It should not be used as a substitute for a constant voltage power supply for standard sign modules.
Is this a good driver for a compact high-output LED array?
Yes, it is designed for constant current LED arrays that need 1750mA and fall within a 12-37V CC range. With 64.75W available, it is better suited to higher-power arrays than lower-current LDH models.
What LEDs can I pair with the LDH-65-1750W?
The LED load must be specified for constant current operation at 1750mA, and the combined LED forward voltage must remain within the 12-37V CC output range. The number of LEDs depends on each LED's forward voltage, so it cannot be defined by a single fixed count.
How does the LDH-65-1750W compare with the rest of the LDH-65 range?
Within the LDH-65 range, the sibling specs are: LDH-65-700 and LDH-65-700W at 700mA with a 12-80V CC range and 56W, LDH-65-1050 and LDH-65-1050W at 1050mA with a 12-60V CC range and 63W, LDH-65-1400 and LDH-65-1400W at 1400mA with a 12-46V CC range and 64.4W, and LDH-65-1750 at 1750mA with a 12-37V CC range and 64.75W. The LDH-65-1750W matches the LDH-65-1750 electrically, with the listed product difference being wire style versus pin style.
