Mean Well ELG-100-C1050AB Power Supply 100W 1050mA - Adjustable and Dimmable
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well ELG-100-C1050AB Power Supply 100W 1050mA - Adjustable and...
The ELG-100 is a 100W Mean Well power converter (input range: 100~305VAC).
Key Features
- ✓ Input voltage range: 100~305VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: IEC62386-101, 102, 207 for DA-Type only
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesELG-C Series
-
Power Rating99.75 Watt
-
Output Voltage105 Volt
-
Rated Current1.05 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming Control0-10V,10V PWM,Resistance
-
Standards MetBSI,CB,CCC,CE,EAC,ENEC,RCM,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length7.83 in
-
Width2.48 in
-
Height1.4 in
-
Weight1.87 lb
::specification::
Frequently Asked Questions
Can the ELG-100-C1050AB be used in a dimmable LED downlight system controlled by a 0-10V wall dimmer?
Yes. The 'AB' suffix indicates both dimming capability and an analog output-adjustment interface. The driver supports 0-10V (as well as PWM and resistance) dimming signals, making it compatible with standard 0-10V architectural dimming systems.
Is the ELG-100-C1050AB suitable for LED retail signage that needs both field-adjustable brightness and remote dimming?
Yes. The combination of output adjustment (A) and dimming (B) in this model lets system designers set a base output level and then dim the sign from a central controller. The driver operates at 1050mA constant current with a CC range of 48–95V.
What IP rating does the ELG-100-C1050AB carry for semi-outdoor installations?
The ELG-100-C1050AB is rated IP65, protecting against dust ingress and low-pressure water jets. It is suitable for covered outdoor enclosures and sign cabinets but is not intended for direct rain exposure without additional housing protection.
What LED string voltages are compatible with the ELG-100-C1050AB?
The constant current output voltage range is 48–95V. Any series-connected LED string whose combined forward voltage falls in that range is compatible; the LED count per string depends on each LED's forward voltage.
Can the ELG-100-C1050AB operate on both residential 120V and commercial 277V AC supplies?
Yes. The universal input of 100–305VAC covers both 120V residential and 277V commercial single-phase supplies used in North America, as well as 230V European grids.
How does the ELG-100-C1050AB differ from the ELG-100-C1050B?
Both share the same 99.75W / 1050mA / 48–95V CC specifications and IP65 rating. The ELG-100-C1050B provides dimming only, while the ELG-100-C1050AB adds an output-adjustment trim interface in addition to the dimming function.
