Mean Well SP-480-12 Power Supply 480W 12V
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well SP-480-12 Power Supply 480W 12V
The SP-480 is a 480W Mean Well power converter (input range: 85~264VAC).
Key Features
- ✓ Input voltage range: 85~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3KVAC reinforced I/O isolation
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL60950-1, TUV EN60950-1
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesMean Well SHP Series
-
Power Rating480 Watt
-
Output Voltage12 Volt
-
Rated Current40 Ampere
-
Input Voltage85V~264V
-
No of Output1
-
Standards MetBSMI,CB,CCC,CE,EAC,RCM,TUV,UL
-
Operating Temperature-20°C~60°C
-
Warranty3 Year
-
Length10.94 in
-
Width5 in
-
Height1.69 in
-
Weight3.75 lb
::specification::
Frequently Asked Questions
Can I use the SP-480-12 for a 12V industrial control panel or automation cabinet?
Yes, it is a 12V single-output power supply rated for 480W and 40A. Its 85-264VAC input range also fits facilities that need broad AC input compatibility.
Is the SP-480-12 suitable for high-current 12V LED lighting or signage systems?
It can support 12V lighting or signage systems that need up to 480W total and up to 40A output current. This model is intended for applications that require a single 12V output at higher power.
Can this 12V power supply run embedded or DC-powered industrial electronics that need a large 12V rail?
Yes, the SP-480-12 is designed for 12V systems and provides up to 40A from a single output. That makes it relevant for embedded, industrial, or automation equipment built around a 12V DC power bus.
Is the SP-480-12 appropriate for indoor or outdoor use?
The published specs list an operating temperature range of -20°C to +60°C. No IP rating is listed in the provided specs, so the product data supports temperature guidance but does not establish outdoor or weather-exposed suitability.
How does the SP-480-12 compare with the other SP-480 models?
Within the SP-480 family, the SP-480-12 is 480W at 12V and 40A. Other listed SP-480 versions are SP-480-15 at 480W, 15V, 32A; SP-480-24 at 480W, 24V, 20A; SP-480-3.3 at 480W, 3.3V, 85A; SP-480-48 at 480W, 48V, 10A; and SP-480-5 at 280.5W.
