Mean Well MPS-65-13.5 Power Supply 65W 13.5V
MEAN WELL MPS-65 Series Power Supplies are 65W singlel output medical type power supplies with 3 years warranty.
Key Features
- ✓Universal AC input / Full range
- ✓Low leakage current <250pA
- ✓Protections: Short circuit / Overload / Over voltage
- ✓Cooling by free air convection
- ✓Medical safety approved (2 x MOPP between primary to secondary)
- ✓100% full load burn-in test
- ✓Fixed switching frequency at 45KHz
- ✓3 years warranty
-
BrandMean Well
-
SeriesMPS Series
-
Power Rating63.45 Watt
-
Output Voltage13.5 Volt
-
Rated Current4.7 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~60°C
-
Warranty3 Year
-
Length5 in
-
Width2.99 in
-
Height1.65 in
-
Weight0.51 lb
::specification::
Frequently Asked Questions
Can I use the MPS-65-13.5 for a 13.5V industrial control panel or alarm enclosure?
It can fit 13.5V industrial or control-panel loads that need constant-voltage output and stay within 4.7A and 63.45W. Its universal 90-264VAC input also helps when the AC source may vary by site. Check that the connected equipment is specified for 13.5V DC, not 12V or 15V.
Is this power supply suitable for 13.5V communications or monitoring equipment?
This model is intended for equipment that requires a regulated 13.5V DC supply and draws no more than 4.7A. That makes it a practical fit for low-power communications, monitoring, or signal-processing hardware designed around 13.5V constant voltage. The available output power is 63.45W.
Can the MPS-65-13.5 power embedded electronics or bench test fixtures that run on 13.5V?
Yes, if the embedded assembly or test fixture needs constant 13.5V DC and the total load remains within 4.7A and 63.45W. The compact 127.0 x 76.0 x 42.0 mm housing can also matter where space is limited. Verify the device's rated input voltage before selecting it.
How does the MPS-65-13.5 compare with the other MPS-65 output options?
Within the MPS-65 range, the options are 3.3V 12A 39.6W, 5V 12A 60W, 7.5V 8A 60W, 12V 5.2A 62.4W, 13.5V 4.7A 63.45W, 15V 4.2A 63W, 24V 2.7A 64.8W, 27V 2.4A 64.8W, and 48V 1.35A 64.8W. The main difference is the output voltage and matching current capacity for each version. This specific model is the 13.5V variant rated at 4.7A.
Is the MPS-65-13.5 suitable for outdoor or harsh-environment use?
The provided specs list an operating temperature of -10°C to +60°C, but no IP rating is given. Based on that spec set, it is better treated as a power supply for protected indoor equipment rather than an exposed outdoor location. If your application needs dust or water resistance, the listing does not state that for this model.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other MPS-65 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well MPS-65-48 Power Supply 65W 48V | 64.8W | 48V | 1.35A | Indoor | $41.88 | View |
| Mean Well MPS-65-7.5Power Supply 65W 7.5V | 60W | 7.5V | 8A | Indoor | $41.88 | View |
| Mean Well MPS-65-5 Power Supply 65W 5V | 60W | 5V | 12A | Indoor | $40.28 | View |
| Mean Well MPS-65-3.3 Power Supply 65W 3.3V | 39.6W | 3.3V | 12A | Indoor | $41.88 | View |
| Mean Well MPS-65-27 Power Supply 65W 27V | 64.8W | 27V | 2.4A | Indoor | $41.88 | View |
| Mean Well MPS-65-24 Power Supply 65W 24V | 64.8W | 24V | 2.7A | Indoor | $41.88 | View |
| Mean Well MPS-65-15 Power Supply 65W 15V | 63W | 15V | 4.2A | Indoor | $41.88 | View |
| Mean Well MPS-65-12 Power Supply 65W 12V | 62.4W | 12V | 5.2A | Indoor | $41.13 | View |
