Mean Well MPS-65-5 Power Supply 65W 5V
MEAN WELL MPS-65 Series Power Supplies are 65W singlel output medical type power supplies with 3 years warranty.
Key Features
- ✓Universal AC input / Full range
- ✓Low leakage current <250pA
- ✓Protections: Short circuit / Overload / Over voltage
- ✓Cooling by free air convection
- ✓Medical safety approved (2 x MOPP between primary to secondary)
- ✓100% full load burn-in test
- ✓Fixed switching frequency at 45KHz
- ✓3 years warranty
-
BrandMean Well
-
SeriesMPS Series
-
Power Rating60 Watt
-
Output Voltage5 Volt
-
Rated Current12 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~60°C
-
Warranty3 Year
-
Length5 in
-
Width2.99 in
-
Height1.65 in
-
Weight0.51 lb
::specification::
Frequently Asked Questions
Can I use the MPS-65-5 for a 5V industrial controller or logic circuit?
Yes, this is a constant-voltage 5V supply rated for 12A and 60W. It is suited to industrial or embedded electronics that require a stable 5V rail and fit within that current and power budget.
Is the MPS-65-5 a good fit for 5V HMI, SBC, or embedded computing loads?
It can be used where the equipment needs 5V DC and the total draw stays at or below 12A and 60W. The 90-264VAC input also makes it practical for systems powered from a broad AC input range.
Can this model power multiple 5V automation modules from one supply?
It can, as long as the combined 5V load does not exceed 12A or 60W. That makes it relevant for grouped 5V control, interface, or embedded loads that share a common constant-voltage source.
Is the MPS-65-5 meant for indoor or outdoor use?
The specified operating range is -10°C to +60°C. The provided specs do not list an IP rating, so the product data does not define it for outdoor, wet, or dust-exposed environments.
How does the MPS-65-5 compare with other 5V MPS power supplies?
Among the listed 5V siblings, MPS-30-5 is 25W at 5A, MPS-45-5 is 40W at 8A, MPS-65-5 is 60W at 12A, MPS-120-5 is 110W at 22A, and MPS-200-5 is 200W at 40A. All are 5V constant-voltage models, with the main difference being current and total wattage.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other MPS-65 Models
8 other models| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well MPS-65-48 Power Supply 65W 48V | 64.8W | 48V | 1.35A | Indoor | $41.88 | View |
| Mean Well MPS-65-7.5Power Supply 65W 7.5V | 60W | 7.5V | 8A | Indoor | $41.88 | View |
| Mean Well MPS-65-3.3 Power Supply 65W 3.3V | 39.6W | 3.3V | 12A | Indoor | $41.88 | View |
| Mean Well MPS-65-27 Power Supply 65W 27V | 64.8W | 27V | 2.4A | Indoor | $41.88 | View |
| Mean Well MPS-65-24 Power Supply 65W 24V | 64.8W | 24V | 2.7A | Indoor | $41.88 | View |
| Mean Well MPS-65-15 Power Supply 65W 15V | 63W | 15V | 4.2A | Indoor | $41.88 | View |
| Mean Well MPS-65-13.5 Power Supply 65W 13.5V | 63.45W | 13.5V | 4.7A | Indoor | $41.88 | View |
| Mean Well MPS-65-12 Power Supply 65W 12V | 62.4W | 12V | 5.2A | Indoor | $41.13 | View |
