Mean Well HVGC-100-350A Power Supply 75W 350mA - Adjustable
The HVGC-100 is a 100W Mean Well DIN rail power converter with a 236mm profile (input range: 180~528VAC).
Key Features
- ✓ 236mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 180~528VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: , UL8750 CSA C22.2 No. 250.0-08, TUV EN61347-1, EN61347-2-13, design refer to UL60950-1, TUV EN60950-1 EAC TP TC 004 IP65 or IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesHVGC Series
-
Power Rating99.75 Watt
-
Output Voltage285 Volt
-
Rated Current0.35 Ampere
-
Input Voltage180V~528V
-
No of Output1
-
Dimming ControlBuilt-in Potentiometer
-
Standards MetCB,CE,EAC,FCC,TUV,UL
-
Operation ModeConstant Current
-
Operating Temperature-40°C~90°C
-
Warranty5 Year
-
Length9.29 in
-
Width2.68 in
-
Height1.53 in
-
Weight2.6 lb
::specification::
Frequently Asked Questions
Can I use the HVGC-100-350A for LED downlights that need a constant current driver?
Yes, this model is a constant current LED driver with a 350mA output and a 29-285V constant current range. It is suited to LED downlights built around a 350mA drive current, as long as the full LED load stays within 29-285V and 99.75W. It is not a constant voltage driver.
Is the HVGC-100-350A suitable for powering a long string of signage LEDs or small LED arrays?
It can work for signage modules or small LED arrays that are designed for constant current operation at 350mA. The available constant current range is 29-285V, so the total forward voltage of the LED load must fall inside that window and stay within 99.75W. Whether it supports a short or long series string depends on each LED's forward voltage.
Can this driver be used in outdoor or damp locations?
This version is rated IP65 water-resistant, so it is intended for environments where resistance to dust and water spray is needed. It is also specified for operation from -40°C to +90°C, which supports demanding ambient conditions. For harsher washdown or full-submersion exposure, the IP rating should be reviewed carefully against the site conditions.
Will the HVGC-100-350A work for custom LED arrays where the LED count may vary?
Yes, if the array is a constant current design that requires 350mA and the total LED forward voltage falls within 29-285V. The exact number of LEDs cannot be fixed from the driver alone because it depends on the forward voltage of each LED in the array. This is a constant current unit, so it should be matched to LED loads that are specified that way rather than constant voltage loads.
What is the difference between the HVGC-100-350A and the other HVGC-100 current options?
Within the HVGC-100 family, the 350mA versions are rated at 99.75W with a 29-285V constant current range, while the 700mA versions are rated at 99.4W with a 15-142V constant current range. The A, AB, and B versions keep those same electrical ratings within each current group. On the listed 350mA models, A and AB are IP65 and B is IP67.
