Mean Well NGE90I12-P1J AC-DC Wall-mounted Green Adaptor - Interchangeable Plug - 75W 12V 6.25A
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well NGE90I12-P1J AC-DC Wall-mounted Green Adaptor - Interchan...
The NGE90I12 is a 90W Mean Well power converter (input range: 80~264VAC, operating temperature: -30~+70℃).
Key Features
- ✓ Input voltage range: 80~264VAC
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Short circuit / Overload / Over voltage
- ✓ Safety approvals: energy when it is under either the operating mode or the standby mode. The entire series is
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesNGE Series
-
Power Rating75 Watt
-
Output Voltage12 Volt
-
Rated Current6.25 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNon Dimmable
-
Standards MetCB,CCC,CE,cUL,DEKRA,EAC,FC,ROHS,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length2.44 in
-
Width1.18 in
-
Height3.37 in
-
Weight0.53 lb
::specification::
Frequently Asked Questions
What are the main output specifications of the Mean Well NGE90I12-P1J?
This model is a 75W AC-DC wall-mounted adaptor with a 12V DC output and a rated current of 6.25A. It is designed for applications that require a regulated 12V supply from a compact external power source.
What makes the NGE90I12-P1J suitable for international or multi-region use?
The NGE90I12-P1J supports a universal AC input range of 80 to 264VAC and features interchangeable AC plugs. It is also backed by multiple global safety certifications across ITE, medical, household, and industrial standards, which makes it practical for broad deployment requirements.
Is this adaptor intended for energy-efficient applications?
Yes. This model meets Energy Efficiency Level VI and has very low no-load power consumption of less than 0.075W. That makes it a strong option for applications where standby power draw matters.
Can this power adaptor be used in demanding temperature conditions?
Yes, the NGE90I12-P1J is rated for operation from -30°C to +70°C. This wide working temperature range makes it suitable for environments that are too hot or too cold for many standard desktop adaptors.
What protections are built into the Mean Well NGE90I12-P1J?
This adaptor includes protection against short circuit, overload, and over voltage. For this 12V model, overload protection uses hiccup mode and recovers automatically after the fault condition is removed.
What types of applications is the NGE90I12-P1J commonly suited for?
This model is best suited to equipment that needs an external regulated 12V DC supply up to 6.25A, especially where a slim wall-mounted form factor is preferred. Its certification coverage also makes it relevant for buyers evaluating use in ITE, medical, household, or industrial equipment programs.
