Mean Well NPF-200-12 Power Supply 200W 12V
The NPF-200 is a 200W Mean Well DIN rail power converter with a 195mm profile (input range: 100~305VAC, operating temperature: -40~+85℃).
Key Features
- ✓ 195mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 100~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -40~+85℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750(type”HL”), CSA C22.2 No. 250.13-12, According to EN61347-2-13 appendix J suitable for emergency installations. ENEC BS EN/EN61347-1, BS EN/EN61347-2-13, BS EN/EN62384 independent, EAC TP TC 004, GB19510.1,GB19510.14,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesNPF Series
-
Power Rating200 Watt
-
Output Voltage12 Volt
-
Rated Current15 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming ControlNon Dimmable
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length7.68 in
-
Width2.68 in
-
Height1.56 in
-
Weight2.27 lb
::specification::
Frequently Asked Questions
Is the NPF-200-12 suitable for outdoor or wet-location LED installations?
Yes. The NPF-200-12 is IP67 rated, providing complete dust protection and resistance to temporary water immersion. Its operating temperature range of -40°C to +85°C supports outdoor lighting deployments across most climates. Note that it requires a minimum of 100VAC input, so it is not compatible with 90VAC supply voltages.
What high-power 12V LED applications is the NPF-200-12 suited for?
The NPF-200-12 delivers 12V DC at 15A (200W) in constant-current mode. This high current output makes it appropriate for large 12V LED strip installations, 12V architectural area lighting with multiple parallel runs, and industrial machine lighting requiring up to 200W from a single driver. Its Class II isolated plastic design removes the need for a protective earth conductor.
How does the NPF-200-12 compare to the NPF-120-12 at the same 12V output?
Both are IP67 rated with Class II design and UL/CE/CB certification. The NPF-200-12 outputs 200W at 15A from a 195.0 × 68.0 × 39.5 mm housing (1.03 kg) and requires 100–305VAC input. The NPF-120-12 outputs 120W at 10A from a smaller 191.0 × 63.0 × 37.5 mm housing (0.97 kg) and accepts 90–305VAC. Choose the NPF-200-12 when the load exceeds 120W or when 15A constant-current is needed.
What is the minimum input voltage for the NPF-200-12?
The NPF-200-12 requires a minimum of 100VAC input, up to a maximum of 305VAC. Unlike the 90VAC minimum on the NPF-120 series, this 100VAC floor means it will not operate reliably on supply voltages that dip below 100VAC — such as heavily loaded branch circuits in some regions. Confirm that your mains supply maintains at least 100VAC under load.
