Mean Well NPF-200-48 Power Supply 200W 48V
The NPF-200 is a 200W Mean Well DIN rail power converter with a 195mm profile (input range: 100~305VAC, operating temperature: -40~+85℃).
Key Features
- ✓ 195mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 100~305VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Cooling by free air convection
- ✓ Wide operating temperature: -40~+85℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750(type”HL”), CSA C22.2 No. 250.13-12, According to EN61347-2-13 appendix J suitable for emergency installations. ENEC BS EN/EN61347-1, BS EN/EN61347-2-13, BS EN/EN62384 independent, EAC TP TC 004, GB19510.1,GB19510.14,IP67
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesNPF Series
-
Power Rating200 Watt
-
Output Voltage48 Volt
-
Rated Current4.17 Ampere
-
Input Voltage100V~305V
-
No of Output1
-
Dimming ControlNon Dimmable
-
Standards MetCB,CCC,CE,EAC,ENEC,UL
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-40°C~85°C
-
Warranty5 Year
-
Length7.68 in
-
Width2.68 in
-
Height1.56 in
-
Weight2.27 lb
::specification::
Frequently Asked Questions
Is the NPF-200-48 rated for outdoor or wet-location use?
Yes. The NPF-200-48 is IP67 rated and has an operating temperature range of -40°C to +85°C. These characteristics make it appropriate for installation inside outdoor luminaires, tunnel lighting fixtures, and industrial enclosures that experience moisture or temperature extremes.
What high-power 48V LED applications suit the NPF-200-48?
The NPF-200-48 delivers 48V DC at 4.17A (200W) in constant-current mode. It suits 48V LED modules in commercial outdoor area lighting, large-format industrial high-bays, stadium perimeter lighting, and transportation infrastructure lighting where 200W of 48V drive capacity is needed.
How does the NPF-200-48 compare to the NPF-200-54?
Both share IP67, the 195.0 × 68.0 × 39.5 mm housing, 1.03 kg weight, and 100–305VAC input. NPF-200-48 outputs 48V at 4.17A (200W); NPF-200-54 outputs 54V at 3.71A (200W). The only difference is the output voltage and current; select based on your LED module's rated voltage.
Does the NPF-200-48 have a protective earth terminal?
No. The NPF-200-48 is a Class II device with a fully isolated plastic case and no FG (functional ground) terminal. The double-insulation design means no chassis earth connection is required, which simplifies cabling in installations where a ground wire is not available or desired.
