Over 15 years experience of providing support of MEAN WELL Power Supplies
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
Mean Well NSP-3200-24 3192W 24V Compact Power Supply
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well NSP-3200-24 3192W 24V Compact Power Supply
The MEAN WELL NSP-320 series is a 320W high-reliability AC/DC enclosed power supply designed for multi-industry applications including industrial automation, mechanical equipment, medical devices, security systems, telecommunications, and PoE power sourcing. With a universal 85–305VAC input and built-in active PFC, it delivers up to 93.5% efficiency and extremely low no-load power consumption for enhanced energy savings. The compact 179×99×30 mm design incorporates forced-air cooling with a DC fan, enabling stable performance across a wide operating temperature range from –40°C to +85°C. Featuring 200% peak power capability, constant current limiting, remote ON/OFF control, remote sense, DC OK signal, and fan ON/OFF temperature control, the NSP-320 series ensures dependable performance in demanding environments. It meets a broad range of global safety standards, including IEC/EN/UL 62368-1, 60601-1 (2×MOPP), 60335-1, 61010-1, and 62477-1, making it suitable for BF-rated medical applications and high-altitude installations up to 5000 meters.
Key Features
-
BrandMean Well
-
SeriesNSP Series
-
Power Rating3192 Watt
-
Output Voltage24 Volt
-
Rated Current133 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Standards MetCB,CE,EAC,TUV,UL
-
Operation ModeConstant Voltage
-
Operating Temperature-20°C~70°C
-
Warranty5 Year
-
Length12.83 in
-
Width4.21 in
-
Height1.61 in
-
Weight4.94 lb
::specification::
Frequently Asked Questions
What is the output rating of the Mean Well NSP-3200-24?
The Mean Well NSP-3200-24 is a 24V enclosed AC/DC power supply rated at 3192W. It provides up to 133A of rated current, making it suitable for high-power industrial and commercial DC loads. This model is designed for applications that need substantial 24V output capacity from a compact enclosed supply.
What types of applications is the NSP-3200-24 typically used for?
This model is intended for demanding applications such as industrial automation, mechanical equipment, telecommunications, network systems, PoE power sourcing, medical devices, and charging systems. Its high output capacity and high-reliability design make it a strong fit for professional environments rather than light-duty consumer use. Buyers typically choose it when they need a robust 24V supply for continuous operation.
Is the NSP-3200-24 suitable for harsh operating environments?
Yes. The product data lists an operating temperature range of -20°C to 70°C, and the product description highlights a high-reliability design for demanding environments. It also uses forced-air cooling and a conformal coated PCB to support durability in industrial conditions.
Does the NSP-3200-24 support energy-efficient operation?
Yes. The product description states efficiency up to 93.5% and built-in active power factor correction. Those characteristics help reduce wasted energy and support more efficient operation in high-power systems.
What monitoring and control features are included on the NSP-3200-24?
According to the product description, this model includes remote ON/OFF control, remote sense, a DC OK signal, and fan ON/OFF temperature control. These features are useful in systems that need status monitoring and tighter power-supply management. They can help support more advanced equipment designs without changing the core 24V output rating.
Does the NSP-3200-24 include built-in protection features?
Yes. The description lists constant current limiting and multiple protections including short circuit, overload, overvoltage, and overtemperature protection. These protections are important for reducing risk in high-power applications and supporting long-term reliability.
How does the NSP-3200-24 compare with lower-power 24V enclosed power supplies?
The main differentiator is output capacity: this model is rated for 24V output at up to 133A, which places it in a much higher-power class than standard 24V enclosed supplies. It is better suited to large DC loads, centralized power architectures, and industrial systems where lower-wattage models would be undersized. Buyers typically select it when power headroom and reliability are more important than minimizing size or cost.
What warranty comes with the Mean Well NSP-3200-24?
This model includes a 5-year warranty. That longer warranty period aligns with its positioning as a high-reliability enclosed power supply for professional and industrial use. It can be an important consideration for buyers evaluating lifecycle value and support expectations.
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other NSP-3200 Models
1 other model| Model | Power | Voltage | Current | IP Rating | Price | |
|---|---|---|---|---|---|---|
| Mean Well NSP-3200-48 3216W 48V Compact Power Supply | 3216W | 48V | 67A | Indoor | $535.38 | View |
