Mean Well PB-120P-27C Portable Battery Chargers 118.68W 27.6V 4.3A ...
EN55022(CISPR22) Class B,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024
Key Features
- ✓AC input range selected by switch
- ✓Built-in passive PFC function compliance to EN61000-3-2
- ✓With AC ON-OFF switch
- ✓3 poles AC inlet with fuse holder
- ✓Protections: Short circuit / Overload / Over voltage / Over temperature
- ✓Charger type can be selected (Optional)
- ✓Charger for lead-acid batteries
- ✓2 color LED loading indicator
- ✓Open frame models available (Without safety approval)
- ✓Low cost, High reliability
- ✓2 years warranty
-
BrandMean Well
-
SeriesPB Series
-
Power Rating118.68 Watt
-
Output Voltage27.6 Volt
-
Rated Current4.3 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Standards MetCB,CE,cUL,EAC,TUV
-
Operation ModeConstant Voltage
-
Operating Temperature-10°C~45°C
-
Warranty2 Year
-
Length7.09 in
-
Width3.78 in
-
Height1.93 in
-
Weight2.73 lb
::specification::
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Other PB-120P Models
4 other models| Model | Power | Battery Type | Battery Voltage | Charging Current | Price | |
|---|---|---|---|---|---|---|
| Mean Well PB-120P-54P Portable Battery Chargers 121.44W 55.2V 2.2A - Single Output Power Supply | 121.44 Watt | Lead Acid Battery | 48V | — | $41.36 | View |
| Mean Well PB-120P-54C Portable Battery Chargers 121.44W 55.2V 2.2A - Single Output Power Supply | 121.44 Watt | Lead Acid Battery | 48V | — | $59.22 | View |
| Mean Well PB-120P-27P Portable Battery Chargers 118.68W 27.6V 4.3A - Single Output Power Supply | 118.68 Watt | Lead Acid Battery | 24V | — | $41.36 | View |
| Mean Well PB-120P-13C Portable Battery Chargers 99.36W 13.8V 7.2A - Single Output Power Supply | 99.36 Watt | Lead Acid Battery | 12V | — | $59.22 | View |
