Mean Well PLC-30-27 Power Supply 30W 27V - PFC
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well PLC-30-27 Power Supply 30W 27V - PFC
The PLC-30 is a 30W Mean Well power converter (input range: 90~264VAC, operating temperature: -30~+50℃).
Key Features
- ✓ Input voltage range: 90~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+50℃
- ✓ Protections: Short circuit / Over voltage / Over temperature
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL1310, TUV EN61347-1, EN61347-2-13, GB19510.14,GB19510.1 , CAN/CSA C22.2 No. 223-M91(except for 48V), J61347-1, J61347-2-13 ,EAC TP TC 004
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLC Series
-
Power Rating30.24 Watt
-
Output Voltage27 Volt
-
Rated Current1.12 Ampere
-
Input Voltage90V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CCC,CE,CSA,EAC,PSE,TUV
-
Operation ModeConstant Current,Constant Voltage
-
Operating Temperature-30°C~50°C
-
Warranty2 Year
-
Length6.3 in
-
Width1.81 in
-
Height1.18 in
-
Weight0.44 lb
::specification::
Frequently Asked Questions
What are the main electrical ratings of the Mean Well PLC-30-27?
The Mean Well PLC-30-27 is rated for 30W output power with a 27V DC output and 1.12A rated current. It also includes active power factor correction and is described as operating in C.V.+C.C. mode with adjustable output voltage and current level.
What type of applications is the PLC-30-27 designed for?
This model is intended for LED driver and power supply applications where a 27V output is required. Its constant voltage operation with built-in constant current limiting makes it relevant for commercial and industrial lighting-related use cases.
What distinguishes the PLC-30-27 from a basic non-PFC power supply?
The PLC-30-27 includes built-in active PFC, with a power factor greater than 0.9 at 75% load or higher. Compared with a basic non-PFC unit, that makes it better suited to applications where power quality and compliance-related performance matter.
What operating temperature range is supported by the PLC-30-27?
This model is specified for operation from -30°C to 50°C. That range makes it suitable for demanding indoor or protected-environment applications where ambient conditions can vary significantly.
Is the PLC-30-27 a constant voltage power supply or a constant current LED driver?
The PLC-30-27 is described as operating in C.V.+C.C. mode, meaning it is a constant voltage power supply with built-in constant current limiting behavior. For buyers, that means the unit is centered around its 27V output while adding current-limiting protection characteristics.
What protection and enclosure features does the Mean Well PLC-30-27 include?
This model has a fully isolated plastic case and uses free air convection for cooling. The listed protections include short circuit, over current, over voltage, and over temperature, and it is identified as a Class 2 power unit that passes LPS.
