Mean Well PLM-25E-500 AC-DC Single output LED driver Constant Current 0.5A 30-50Vdc
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well PLM-25E-500 AC-DC Single output LED driver Constant Curre...
The PLM-25E is a 25W Mean Well DIN rail power converter with a 145mm profile (input range: 110~295VAC, operating temperature: -30~+45℃).
Key Features
- ✓ 145mm width — DIN rail TS-35 compatible
- ✓ Input voltage range: 110~295VAC
- ✓ 3.75KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+45℃
- ✓ Protections: Short circuit
- ✓ Active PFC — meets international energy efficiency regulations
- ✓ Safety approvals: UL8750, CSA C22.2 No. 250.13-12(for Blank type only); ENEC EN61347-1, EN61347-2-13, EN62384, GB19510.14,GB19510.1 (for E type only) ,EAC TP TC 004, IP30
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesPLM Series
-
Power Rating25 Watt
-
Output Voltage56 Volt
-
Rated Current0.5 Ampere
-
Input Voltage180V~295V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,EAC,ENEC,UL
-
Operation ModeConstant Current
-
Operating Temperature-30°C~45°C
-
Warranty2 Year
-
Length5.71 in
-
Width1.5 in
-
Height0.87 in
-
Weight0.28 lb
::specification::
Frequently Asked Questions
What kind of LED application is the Mean Well PLM-25E-500 designed for?
The PLM-25E-500 is a constant current LED driver for fixtures that require a fixed 500 mA output. It is suited to LED assemblies operating within the model's stated current and output range, rather than constant-voltage loads. Its 25 W rating makes it a fit for lower-power commercial or architectural LED applications.
What are the main electrical specs of the PLM-25E-500?
This model is rated at 25 W with a constant output current of 500 mA. The product name identifies it as a 30-50 Vdc constant current LED driver. It is part of Mean Well's PLM enclosed LED driver range with built-in active PFC and short-circuit protection.
What input range does the PLM-25E-500 support?
The PLM-25E-500 is the E-type version in this series, which the product data lists for 180-295 VAC input. That makes it appropriate for 230 VAC markets rather than universal 110 VAC input applications. Buyers needing broader AC input coverage should check the non-E version in the same PLM-25 family.
Is the PLM-25E-500 suitable for enclosed or touch-accessible lighting products?
This model uses a fully isolated plastic case and is described as a Class II power unit, so it is built for isolated LED driver use. The plastic enclosure and free-air convection cooling make it suitable where a compact enclosed driver format is needed. Final suitability still depends on the fixture's thermal and compliance requirements.
What operating environment is this LED driver rated for?
The listed operating temperature range is -30 C to 45 C. Cooling is by free air convection, so it is intended for applications that can stay within that ambient range without forced cooling. It is a better fit for indoor or protected environments that match those thermal limits.
Does the PLM-25E-500 include dimming?
No. The product data lists dimming control as none, so this model is intended for non-dimming constant current LED applications. If dimming is required, a different driver series or variant would be a better choice.
What warranty comes with the Mean Well PLM-25E-500?
The specified warranty period for this model is 2 years. That aligns with the product description for the PLM series entry provided here. For procurement or project documentation, this gives a clear baseline warranty term for the driver.
