Mean Well RPS-120-15-C Green Power Supply W 15V 8A - Medical Power Supply
Notify me when it's back in stock
Your order will be processed within 24 hours
Mean Well RPS-120-15-C Green Power Supply W 15V 8A - Medical Power ...
The RPS-120-15 is a 120W Mean Well power converter (input range: 80~264VAC, operating temperature: -30~+70℃).
Key Features
- ✓ Input voltage range: 80~264VAC
- ✓ DC output voltage adjustable ±10%
- ✓ 4KVAC reinforced I/O isolation
- ✓ Wide operating temperature: -30~+70℃
- ✓ Protections: Overload / Over voltage / Over temperature
- ✓ Safety approvals: ISOLATION RESISTANCE IEC60601-1, TUV EN60601-1, CAN/CSA-C22.2 No. 60601-1:14 - Edition 3
- ✓ 3 years warranty
-
BrandMean Well
-
SeriesRPS Series
-
Power Rating84 Watt
-
Output Voltage15 Volt
-
Rated Current8 Ampere
-
Input Voltage80V~264V
-
No of Output1
-
Dimming ControlNone
-
Standards MetCB,CE,cUL,EAC,SHIDE
-
Operation ModeConstant Voltage
-
Operating Temperature-30°C~70°C
-
Warranty3 Year
-
Length4.07 in
-
Width2.44 in
-
Height1.57 in
-
Weight0.53 lb
::specification::
Frequently Asked Questions
Can I use the RPS-120-15-C in a medical cart or compact medical device that needs 15V DC?
Yes, if the load needs constant 15V DC and stays within 8A or 84W. This model is medical safety approved and keeps those electrical limits in a compact-format power supply.
Is the RPS-120-15-C a fit for 15V lab instruments or test equipment?
It can be used for laboratory or test equipment that requires a constant 15V output and does not exceed 8A. The broad 80-264VAC input range also makes it practical for equipment used in different AC input environments.
Can this model power 15V embedded computers, scanners, or automation modules?
Yes, provided the connected electronics are designed for a constant 15V supply and the total draw remains at or below 84W. Its medical approval and extremely low leakage current can matter where sensitive electronic equipment is involved.
Is the RPS-120-15-C suitable for harsh indoor environments or outdoor exposure?
It is suited to protected indoor use or installation inside a suitable enclosure. The specified operating temperature range is -30°C to +70°C, but no IP rating is provided, so it should not be treated as an exposed outdoor power supply.
What is the difference between the RPS-120-15-C and other RPS-120 output options?
The RPS-120 family includes 12V 10A 84W, 15V 8A 84W, 24V 5A 84W, 27V 4.5A 85W, and 48V 2.5A 84W versions. The RPS-120-15-C is the 15V 8A 84W model, and compared with the non-C RPS-120-15 it has the same electrical rating but different physical specs: 103.4 × 62.0 × 40.0 mm and 0.24 kg versus 101.6 × 50.8 × 29.0 mm and 0.15 kg.
